SPECIFICATIONS
Machine Dimensions
3985 (156.9)
3135 (123.5)
1595 (62.9)
2215 (87.2)
345 (13.5)
1860 (73.2)
←
1570 (61.8)
←
1960 (77.2)
580 (22.8)
←
A 3430 (135.1)
B 2740 (107.8)
C 1390 (54.7)
D 2130 (83.9)
E 310 (12.1)
F 1580 (62.2)
G 320 (12.6)
H 1430 (56.3)
J 980 (38.6)
K 1675 (66.0)
L 510 (20.0)
M30°
Units: mm (inches)
Standard Bucket
Rubber Crawlers
CTL60 CTL80CTL70
3710 (146.0)
2950 (116.1)
1495 (58.9)
2170 (85.4)
325 (12.8)
1770 (69.7)
450 (17.7)
1500 (59.1)
←
1880 (74.0)
535 (21.1)
←
