18 917001/CP0905
Operator’s Seat
The seat is mounted on rails for rearward or
forward repositioning. A spring-loaded
latch handle activates the seat position
adjustment mechanism.
Suspension seat (optional on all models):
A weight adjustment knob is provided
for individual operator adjustment.
Upper-Torso Restraint
Always wear the upper-torso restraint when
operating in high speed.
The seatbelt should always be fastened during operation.
Important: Inspect the seatbelt(s) for damage before use, and replace if dam-
aged. Keep seatbelt(s) clean. Use only soap and water to wash seatbelt(s). Clean-
ing solvents can cause damage to seatbelt(s).
Safety Interlock System
Hydraloc™
NEVER defeat the safety interlock system by
mechanically or electrically bypassing any
switches, relays or solenoid valves.
An interlock system is provided on the loader for operator safety. Together with
solenoid valves, switches and relays, the interlock system:
¾ Prevents the engine from starting unless the operator is sitting on the seat and
the operator restraint bar is lowered.
1
2
3
4
Figure 1 Operator’s Seat
1. Restraint Bar
2. Seatbelt
3. Seat Position Adjustment Lever
4. Suspension Seat Weight
Adjustment Knob (optional)
WARNING
WARNING
