22 917001/CP0905
Heater (optional)
Loaders with the optional heater have a dial on the left instrument panel to con-
trol the fan speed.
Heater and Air Conditioner (optional)
Loaders with the combination heater/ air
conditioner have two controls on the left
instrument panel: fan speed, air condi-
tioner on/off, and temperature.
1. Fan Speed: Controls the rate at
which air exits the vents.
2. Heater/Air Conditioner Selector
Switch: Turns on either the heater or
air conditioner. Center off position
allows fan only operation for air cir-
culation.
Note: The operator will feel cooler with
only the two front vents opened and
aimed at the upper body.
Engine Speed Control
A hand throttle lever (Figure 6) is pro-
vided for adjusting the engine speed.
Move the control forward to increase and
rearward to decrease the engine speed.
Figure 5 Heater/
Air Conditioner Controls
2
1
Figure 6 Hand Throttle Lever
