How to fix a flashing or permanently on Red cross on Gemalto Card Reader?
If the red cross is flashing or permanently on, on your Gemalto Card Reader, it indicates that the reader has failed its self-test or is damaged. Try disconnecting all cables and turning the reader off. Then, plug in the PSU cable and turn it on. Once it has successfully powered up, connect the USB cable.
Why is the demo application not working with my Gemalto AT10Ki Card Reader?
If the demo application isn't working with your Gemalto Card Reader, first verify that only one copy of the application is running. If not, remove the existing application and reinstall the software. Also, check that no other running applications or services have connected to the reader. Close or disable any conflicting applications or services. It's also possible that you lack PC administrative rights.
Why USB peripherals attached to Gemalto AT10Ki do not power on or do not function correctly?
If USB peripherals attached to your Gemalto Card Reader aren't powering on or functioning correctly, it might be because you need to use the external power supply when attaching external devices. Verify the AC power source and ensure that the AC cable is connected to both the AC power source and the power supply port on the back panel.
What to do if my Gemalto Card Reader is not communicating with host PC system?
If your Gemalto Card Reader isn't communicating with the host PC, make sure the USB cable is properly connected. Also, verify that the USB driver is installed correctly. Ensure that only one reader is connected to the host system and that only one instance of the host application is running.
Why my Gemalto Card Reader LEDs do not come on during power up?
If the LEDs on your Gemalto Card Reader don't light up during power up, it could be due to a few reasons. First, check that the reader is properly connected to a USB 2.0 or USB 3.1 host port and/or an external power supply. Another reason could be that the power switch is in the Off position, so ensure the reader is turned on. If the problem persists, the reader might be damaged.
What to do if my Gemalto Card Reader becomes unresponsive?
If your Gemalto Card Reader becomes unresponsive, close and restart the application. Disconnect the USB and PSU from the PC and then reconnect them. Alternatively, disconnect the USB and PSU, close the application, and then restart your PC. Reconnect the document reader to the PC and then open the application.
Why is the Red cross LED illuminating when a document is scanned on my Gemalto AT10Ki Card Reader?
The red cross LED might illuminate when scanning a document with your Gemalto Card Reader for several reasons. It's normal if the document is non-machine readable, indicating that only the image is captured. Alternatively, the document might be poorly printed or not conform to specifications. Ensure that ambient light compensation is enabled in the software SDK, and re-orient the reader to avoid bright light falling directly on the document window. The unit may also not be configured to read the document being scanned.
What does it mean when the green tick is flashing on my Gemalto AT10Ki Card Reader?
A flashing green tick on your Gemalto Card Reader indicates that the USB cable might not be connected properly. Check that the USB cable is connected securely at both ends. Also, inspect the USB cable for any damage. Finally, verify that the PC USB port is not damaged or disabled.
Technical information, recommendations, and statements are based on tests and experience but not guaranteed.
Outlines warranties, remedies, and liability limitations for the product.
Details the version history and release dates of the user guide.
Lists the various types of documents and data formats the reader can process.
Explains the three primary modes of operation: Web-UI, Web-API, and Legacy USB.
Details the available connectivity options for the AT10Ki reader.
Describes the imaging capabilities and technologies used by the reader.
Outlines the physical characteristics and design aspects of the reader.
Lists typical use cases and scenarios for the AT10Ki reader.
Explains how the reader aids in detecting forged or counterfeit documents using various light sources.
Details technologies that ensure accurate, color-calibrated images under various lighting conditions.
Describes the glass surface for document placement and scanning.
Explains the semi-enclosed hood for minimizing ambient light and improving scan quality.
Explains the function and meaning of the status LEDs for operation and self-tests.
Details the ports and connectors located on the back panel of the reader.
Describes the USB 3.1 Type C host port and auxiliary USB 2.0 ports.
Details the RJ45 Ethernet port for network connectivity.
Mentions the availability of a micro-HDMI port for local screen output.
Provides information about the included power supply and safety precautions.
Details powering the reader via USB port or Power Over Ethernet.
Explains the function of the latching rocker type power switch.
Lists the prerequisites and requirements for reader installation.
Details the contents of the reader package and the unpacking procedure.
Guides on downloading and installing the necessary reader software.
Instructions for connecting the USB and optional power supply cables.
Procedure to test if the reader and software are installed and functioning correctly.
Lists prerequisites for installing the reader in networked mode.
Details the contents of the reader package for networked mode.
Guides on downloading and installing the Gemalto Messaging SDK for networked setup.
Instructions for connecting Ethernet and power supply for networked operation.
Steps to test the reader's network functionality and ensure proper operation.
Guides on configuring the reader via its IP address or test application.
Explains how the reader detects and reads contactless RFID chips alongside optical scanning.
Details the initial setup and configuration process for running the reader in a network.
Explains how to update the reader's operating system and SDK over the network.
Describes tools and methods for managing multiple readers in a network environment.
Summarizes the security measures implemented in the reader for data protection and secure operations.
Provides instructions on how to clean the reader's glass surface and body.
Outlines the procedure for replacing the damaged document window glass.
Details the physical dimensions, weight, and imaging window specifications.
Covers input voltage, power consumption, and connector type.
Lists operating and storage temperature, humidity, and dust protection rating.
Details USB, Ethernet, WiFi, Bluetooth, and HDMI interface specifications.
Provides details on input voltage, line frequency, cable length, power rating, and PSU efficiency.
Lists relevant directives and standards the product complies with.
Lists information to prepare before contacting Gemalto Global Technical Services.
Provides contact details for Gemalto's Global Technical Services.
Outlines the step-by-step procedure for returning the reader for repair or maintenance.
Technical information, recommendations, and statements are based on tests and experience but not guaranteed.
Outlines warranties, remedies, and liability limitations for the product.
Details the version history and release dates of the user guide.
Lists the various types of documents and data formats the reader can process.
Explains the three primary modes of operation: Web-UI, Web-API, and Legacy USB.
Details the available connectivity options for the AT10Ki reader.
Describes the imaging capabilities and technologies used by the reader.
Outlines the physical characteristics and design aspects of the reader.
Lists typical use cases and scenarios for the AT10Ki reader.
Explains how the reader aids in detecting forged or counterfeit documents using various light sources.
Details technologies that ensure accurate, color-calibrated images under various lighting conditions.
Describes the glass surface for document placement and scanning.
Explains the semi-enclosed hood for minimizing ambient light and improving scan quality.
Explains the function and meaning of the status LEDs for operation and self-tests.
Details the ports and connectors located on the back panel of the reader.
Describes the USB 3.1 Type C host port and auxiliary USB 2.0 ports.
Details the RJ45 Ethernet port for network connectivity.
Mentions the availability of a micro-HDMI port for local screen output.
Provides information about the included power supply and safety precautions.
Details powering the reader via USB port or Power Over Ethernet.
Explains the function of the latching rocker type power switch.
Lists the prerequisites and requirements for reader installation.
Details the contents of the reader package and the unpacking procedure.
Guides on downloading and installing the necessary reader software.
Instructions for connecting the USB and optional power supply cables.
Procedure to test if the reader and software are installed and functioning correctly.
Lists prerequisites for installing the reader in networked mode.
Details the contents of the reader package for networked mode.
Guides on downloading and installing the Gemalto Messaging SDK for networked setup.
Instructions for connecting Ethernet and power supply for networked operation.
Steps to test the reader's network functionality and ensure proper operation.
Guides on configuring the reader via its IP address or test application.
Explains how the reader detects and reads contactless RFID chips alongside optical scanning.
Details the initial setup and configuration process for running the reader in a network.
Explains how to update the reader's operating system and SDK over the network.
Describes tools and methods for managing multiple readers in a network environment.
Summarizes the security measures implemented in the reader for data protection and secure operations.
Provides instructions on how to clean the reader's glass surface and body.
Outlines the procedure for replacing the damaged document window glass.
Details the physical dimensions, weight, and imaging window specifications.
Covers input voltage, power consumption, and connector type.
Lists operating and storage temperature, humidity, and dust protection rating.
Details USB, Ethernet, WiFi, Bluetooth, and HDMI interface specifications.
Provides details on input voltage, line frequency, cable length, power rating, and PSU efficiency.
Lists relevant directives and standards the product complies with.
Lists information to prepare before contacting Gemalto Global Technical Services.
Provides contact details for Gemalto's Global Technical Services.
Outlines the step-by-step procedure for returning the reader for repair or maintenance.
General| Brand | Gemalto |
|---|---|
| Model | AT10Ki |
| Category | Card Reader |
| Language | English |
