■ Parts Names & Functions
No. Functions No. Functions
1 3.5” LCD display 9 LED brightness dimmer B
2 MicroSD card slot 10 USB port
3 Focus Wheel 11 TV out
4 Microscope tube 12 5v DC in
5 Capture button 13 Gems tweezer hold
6 DC out 14 Battery compartment
7 LED brightness dimmer A 15 Battery charging indicator
8 Zoom +/-
