GEM-P9600 Installation Instructions
L
NAPCO Security Systems
WI742E 2/04
!
Page 50
Time Selection
The following times are programmable:
Any timeout up to those shown in the foregoing table may
be programmed. Note that each of the above times is pro-
grammed in two locations. The first location has an as-
signed time factor of 16, the second a time factor of 1.
*Blank.
Note: If both programming locations are left blank, refer to the notes in the Time Selection table for feature timeout.
To select a time up to 15 seconds, 15 minutes, 15 hours, or 15 days, program the respective entry into the second box only; do
not program the first box. To select a time greater than 15 seconds, 15 minutes, 15 hours or 15 days, program both boxes as follows:
1. For the feature selected, choose an appropriate time in units shown (all seconds, minutes, hours, or days — not minutes
and seconds, etc.).
2. Divide the time chosen by 16. Enter the quotient in the 1st BOX and the remainder in the 2nd BOX.
3. Check entries by adding the contents of the 2nd BOX to 16 times the contents of the 1st BOX. (Remember that a “zero”
entry represents 10.)
Example. Program Entry Delay 1 for 1 minutes.
1. Entry Delay 1 is in units of seconds, thus delay time is 90 seconds.
2. Divide by 16: 90/16 = 5 (quotient) + 10 (remainder).
3. Enter the quotient in the 1st BOX and the remainder in the 2nd BOX
4. Check entries (remember, a “0” entry = 10): (16x5) + 10 = 90
TouchTone Dialing Only
Rotary Dialing Only
TouchTone Dialing with Rotary Backup
Select TouchTone Dialing Only if the subscriber has TouchTone service. TouchTone dialing is faster than rotary dialing, but not
always as reliable.
For the communicator to use TouchTone on all dial attempts, program TouchTone Dialing Only. To use TouchTone on the first
attempt with subsequent Rotary dial, program TouchTone Dialing with Rotary Backup. TouchTone Dialing Only will override Touch-
Tone Dialing with Rotary Backup if both are selected. Note that if Backup Reporting is also selected, the communicator will alternate
between TouchTone and rotary dial to reach Telephone 1, then Telephone 2. See Backup Report on Telco 2.
Trouble
An abnormal zone condition (a break in a normally-closed loop; a short on a normally-open loop; or either on an end-of-line-
resistor supervised loop) when disarmed.
Trouble on a Burglary Zone is automatically displayed at the keypad unless Disable Zone Fault Scrolling (Auto Status) is pro-
grammed. If a Burglary Zone is in trouble, it will go into alarm about 10 seconds after arming. However, if Auto Bypass is pro-
grammed, the keypad will beep upon arming (does not apply to selective- or group-bypassed zones).
GLOSSARY
NOTES:
(1)
The output used for Burglary must be at least 4 minutes
in Residential UL installations, 15 minutes in Commercial UL instal-
lations.
(2)
If both locations are left blank, this feature will remain ac-
tive until the system is disarmed. When both locations are pro-
grammed “F”, maximum time will be 4 hours, 15 minutes (255 min-
utes).
(3)
If both locations are left blank, this feature will not activate
(timeout = 0).
(4)
In UL installations: Maximum Exit Delay = 60 sec;
Maximum Entry Delay = 45 sec.
(5)
If programming locations are left
blank, delay will default to 10 sec.
(6)
Time in units of disarmed hours
(accumulated between armed periods).
TIME
(1)
UNITS MAX. PROG. TIME
RESET OUTPUT MIN. UNTIMED
(2)
AUXILIARY OUTPUT MIN. UNTIMED
(2)
AUXILIARY OUTPUT
ACCESS CONTROL TIME
SEC. 4 MIN, 15 SEC (255 SEC)
BURGLARY OUTPUT MIN. UNTIMED
(1)(2)
PULSE-BURG OUTPUT MIN. UNTIMED
(1)(2)
FIRE OUTPUT MIN. UNTIMED
(2)
ABORT DELAY SEC. 4 MIN, 15 SEC (255 SEC)
(3)
CHIME TIME ¼ SEC. 63.25 SEC (255 QTR-SEC)
(3)
AC-FAIL REPORT DELAY 10 MIN. 42 HR, 30 MIN (2550 MIN)
EXIT DELAY SEC.
4 MIN, 15 SEC (255 SEC)
(4)
ENTRY DELAY 1 SEC.
4 MIN, 15 SEC (255 SEC)
(4)
ENTRY DELAY 2 SEC. 4 MIN, 15 SEC (255 SEC)
(4)
TELCO LINE-TEST DLY 15 SEC. 4 MIN, 15 SEC (255 SEC)
(5)
AUTO DISARM /
REARM DLY
MIN. 4 HR, 15 MIN (255 MIN)
SENSOR-WATCH TIME DISARMED HOURS 255 HOURS
(6)
1st BOX 2nd BOX
tx16 tx1
Time t: 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Entry: * 1 2 3 4 5 6 7 8 9 0 B C D E F
