Genelec 4020B - System Specifications; Crossover Section Details; Amplifier Section Specifications

7
AMPLIFIER SECTION
Bass amplifier output power with an 8 Ohm load: 20 W
Treble amplifier output power with an 8 Ohm load: 20 W
Long term output power is limited by driver unit protection
circuitry.
_____________________________________________
Amplifier system distortion at nominal output:
THD < 0.08 %
SMPTE-IM < 0.08 %
CCIF-IM < 0.08 %
DIM 100 < 0.08 %
_____________________________________________
Signal to Noise ratio, referred to full output:
Bass > 95 dB
Treble > 95 dB
_____________________________________________
Mains voltage:
100, 120, 220 or 230 V
according to region
Voltage operating range: ±10 %
Power consumption:
Idle 5 W
Standby <0,5 W
Full output 50 W
SYSTEM SPECIFICATIONS
Lower cut-off frequency, –3 dB: < 65 Hz
_____________________________________________
Upper cut-off frequency, –3 dB: > 21 kHz
_____________________________________________
Free field frequency response of system:
66 Hz – 20 kHz (± 2.5 dB)
_____________________________________________
Maximum short term sine wave acoustic output on axis in
half space, averaged from 100 Hz to 3 kHz:
@ 1 m > 96 dB SPL
@ 0.5 m > 102 dB SPL
_____________________________________________
Maximum long term RMS acoustic output in same
conditions with IEC weighted noise (limited by driver unit
protection circuit): @ 1 m > 95 dB SPL
_____________________________________________
Maximum peak acoustic output per pair on top of
console, @ 1 m distance with music material: > 105 dB
_____________________________________________
Self generated noise level in free field @ 1m on axis:
< 10 dB (A-weighted)
_____________________________________________
Harmonic distortion at 85 dB SPL @ 1m on axis:
Freq: 50…100 Hz < 3 %
>100 Hz < 0.5 %
_____________________________________________
Drivers: Bass 105 mm (4") cone
Treble 19 mm (
3
/
4
") metal dome
Both drivers are magnetically shielded
_____________________________________________
Weight: 3.6 kg (7.9 lb)
_____________________________________________
Dimensions:
Height 226 mm (8
7
/
8
”)
Width 151 mm (6")
Depth 142 mm (5
5
/
8
”)
CROSSOVER SECTION
Input connector:
Balanced 10 kOhm
_____________________________________________
Input level for 100 dB SPL output at 1 m:
-6 dBu at volume control max
_____________________________________________
Volume control range:
-40 dB relative to max output
_____________________________________________
Crossover frequency, Bass/Treble: 3.0 kHz
_____________________________________________
Treble Tilt control operating range:
0 to –2 dB @ 15 kHz
_____________________________________________
Bass Roll-Off control operating in a –6 dB step @ 85 Hz
_____________________________________________
Bass Tilt control operating range in –2 dB steps:
0 to –6 dB @ 100 Hz
_____________________________________________
The ‘CAL’ position is with all tone controls set to ‘off’ and
the input sensitivity control to maximum (fully clockwise).
