7060B / 7070A / 7071A Data Sheet
AMPLIFIER SECTION
INPUT SECTION
CROSSOVER SECTION
SYSTEM SPECIFICATIONS
7060B 7070A 7071A
Free field frequency response 19 Hz…85 Hz 19 Hz…85 Hz 19 Hz…85 Hz
(+/- 3 dB) LFE 85/120 Hz LFE 85/120 Hz LFE 85/120 Hz
Maximum short term sine wave
SPL output averaged from
30 to 85 Hz, measured in
half space at 1 meter
≥ 108 dB SPL ≥ 112 dB SPL ≥ 118 dB SPL
Maximum peak SPL output with
random pink noise, measured
in half space at 1 meter
≥ 113 dB SPL ≥ 117 dB SPL ≥ 123 dB SPL
Self generated noise level in
free field @ 1 m on axis
(A-weighted)
≤ 15 dB
Harmonic distortion @ 90 dB SPL @ 95 dB SPL @ 100 dB SPL
at @ 1 m on axis in half space 30 … 85 Hz 30 … 85 Hz 30 … 85 Hz
2nd
≤ ≤ 3 % ≤ ≤ 3 % ≤ ≤ 3 %
3rd
≤ ≤ 2 % ≤ ≤ 3 % ≤ ≤ 3 %
Driver, magnetically shielded 250 mm (10”) 305 mm (12”) 2 x 305 mm (12”)
Weight 26 kg (57 lbs) 50 kg (110 lbs) 81 kg (178 lbs)
Dimensions
Height 527 mm (20 3/4”) 625 mm (24 5/8”) 755 mm (29 3/4”)
Width 462 mm (18 3/16”) 555 mm (21 7/8”) 803 mm (31 5/8”)
Depth 363 mm (14 5/16”) 490 mm (19 5/16”) 490 mm (19 5/16”)
7060B 7070A 7071A
Short term amplifier output
power (Long term output power
is limited by driver unit
protection circuitry) 120 W 250 W 500 W
Amplifier system distortion
at nominal output
THD
≤ 0.05%
Mains voltage 100/200 V
or 115/230 V
Power consumption (average)
Idle 15 VA 15 VA 30 VA
Full output 150 VA 250 VA 500 VA
OUTPUT SECTION
CONTROLS
7060B 7070A 7071A
Input connector XLR female
pin 1 gnd
pin 2 +
pin 3 –
Input impedance 10 kOhm balanced
Input level for 100 dB SPL
output @ 1 m Variable from +12 to –6 dBu
7060B 7070A 7071A
Output connector XLR male
pin 1 gnd
pin 2 +
pin 3 –
Remote LED connector (RJ11) Remote LED for Power/Overload+Bypass
Main monitor Out gain 0 dB
Sum Out gain 0 dB
7060B 7070A 7071A
Input sensitivity +12 to –6 dBu
Bypass Bypasses the bass management for the main channels
LFE bandwidth 85 / 120 Hz
LFE sensitivity 0 / +10 dB
Redirect Redirects LFE channel signal above 85 Hz to center channel
Sum in Changes subwoofer to Sum in mode
Test tone for phase adjustment 85 Hz
Bass roll-off 0/-2 dB/ -4 dB/ -6 dB @ 20 Hz
Phase 0/90/180/270°
7060B 7070A 7071A
Subsonic filter
(18 dB/octave) below 19 Hz
Crossover frequency,
(sub/main channels) 85 Hz
LFE cutoff Hz 85 Hz/120 Hz selectable
Crossover slopes
Lowpass 36 dB/octave
Highpass 12 dB/octave
Midband rejection >400 Hz
≥ 50 dB
Bass roll-off control operating From 0 to –6 dB @ 20 Hz
range in 2 dB steps
Phase matching control From 0 to -270° @ 85 Hz
in 90° steps
