Genelec GLM 4 Quick Setup Guide

13
To calibrate a monitoring group
1. Check the serial number of the measurement micro-
phone (measurement microphone calibration le is
retrieved during rst calibration)
2. Select the calibration mode; either a single location
measurement (SinglePoint) or measurements of
multiple measurement positions (MultiPoint). Select
the Symmetrical EQ if a Left/Right pair of monitors
should receive the same calibration lters. The
Individual EQ would be useful for unsymmetrical
setups where one monitor is in a corner and the other
free-standing. In order for the symmetric lters func
tion to be used, monitors need to be symmetrical on
the grid. Monitor pairs not positioned symmetrically
on the grid will be handled as individual units.
3. Connect the measurement microphone to the GLM
network adapter, place the microphone at the listen
ing position, at ear height, and click on the ‘Start
Calibration’ button to start the measurement and
follow the dialog instructions.
- All monitors and subwoofers will be measured,
and if MultiPoint is selected then next position(s)
will be measured.
- Optimization starts.
- Wait until optimization nishes.
- The calibration results can be viewed by clicking
any loudspeaker icon.
4. Click ‘Conrm Calibration’ button to accept and save
the settings to the setup le.
If there is a subwoofer in the group, the next step of
the process is the automatic adjustment of the phase
(AutoPhase).

Genelec GLM 4 Specifications

General

Brand	Genelec
Model	GLM 4
Category	Speaker System
Language	English
