4.5 STATUS INDICATORS
The top right corner shows the system state: ‘Status:
OK’ (all devices are working normally), ‘Status: LS
Ofine’ (one or more monitors in this group are not
reachable by the network), ‘Status: Adapter Ofine’
(GLM Adapter is not connected to the computer).
The loudspeaker states will be indicated with the
following colours (see gure below).
• The loudspeaker icon without any added colour
indicates the normal state.
• The loudspeaker icon with the black background
indicates the loudspeaker is ofine.
• The loudspeaker icon with the red background
indicates the loudspeaker is clipping.
• The loudspeaker icon with the yellow background
indicates the loudspeaker has protection ON.
• The red border of the loudspeaker cell tells that the
loudspeaker is muted.
• The green border of the loudspeaker cell tells that
the loudspeaker is soloed.
Figure 17. GLM status indicators.
