Genelec GLM 4 Quick Setup Guide

7
Table 1. Connections on GLM adapter (from left to right).
CONNECTOR USE
USB (type B) Connection for a USB
cable on your computer.
For stand-alone opera-
tion, connection from a
USB power supply.
Volume (3.5 mm jack) Connection for Genelec
volume controller
Microphone (3.5 mm jack) Connection for Genelec
calibration microphone
GLM Net (RJ45) GLM control network
connection
Terminator (RJ45) Return termination for the
GLM control network
from the last monitor, in
case of network cabling
being greater than
100 meters
Figure 3. Connections of GLM control network,
measurement microphone, and computer.
