19
Item Part # Qty Description
1 AB1770 1 BASE
2 67989 10 NUT, M8 Flange Serr.
3 42909 2 HHCS, M8 1.25 x 30
4 50190 2 WASHER, M8 Flat
5 27007 2 MOUNT, Donut Type Vibration
6 20566 1 DECAL, Generac #1-800
7 B2192 1 DECAL, Generac
8 B2150 1 HOOK , Gun
9 B2516 1 CAP, Vinyl (black)
10 B2043 7 BOLT, 5/16"-18 x 1-3/4"
Carriage
11 B3760 1 DECAL, Logo
12 B1983 1 HANDLE
13 B1631A 1 BILLBOARD, Plastic
14 B1932 1 DECAL, Instructions
15 99583 8 NUT, Flange Lock 5/16"-18
16 B1981 2 SUPPORT, Handle
20 21217 4 MOUNT, Rubber Shock
21 B1232 1 CLAMP, Hose 7/16 Dia.
22 32713 1 SCREW, Taptite #10-32 x 5/8"
23 A1040D 1 HOSE, 4-1/2 Chemical Clear
24 A1041 1 FILTER, Chemical Hose
25 70453 1 TAG, Warning Oil
26 97178 2 KNOB, Handle 1/4" - 20 PW
27 31669 2 BOLT, 1/4" - 20 x 1-3/4"
Carriage
28 B1760 2 ASSEMBLY, 10" Tire & Wheel
29 75402 2 PUSHNUT, .50" Dia.
30 B4095 1 SHEET, Info.
31 B3297 1 MANUAL,Engine
32 B4730 1 MANUAL
Item Part # Qty Description
33 23139B 1 KEY, 3/16" sq. x 1-1/2" Lg.
34 95531 4 SHCS, 5/16" - 24 x 3/4"
35 B3699A 1 ASSEMBLY, Pump
36 B4757 1 CAP, Inlet Quick Connect
37 89647A 1 CONNECTOR, Garden Hose
38 97098 1 CAP, Garden Hose Inlet
39 B1982 1 BUMPER
40 NSP 1 ENGINE
41 B3057 1 KIT, O Ring
42 B4719 1 HOSE, High Pressure
43 87815 1 GOGGLES, Safety
44 B4720 1 GUN, High Pressure
45 B3335C 1 LANCE, Nozzle Hi/Lo
46 97566 1 TAG,Nozzle Instructions
47 B2168A 1 HANGER, Hose, Gun, Jug
48 B1460 2 CAP, Vinyl (black)
49 B2163 1 KIT, Nozzle Cleaning
50 B2203 1 KIT, Handle Fastening
51 92661 1 NOZZLE, 1.20 Blue
Replacement
52 B3213 1 VALVE, Thermal Relief
53 92479 4 LOCK WASHER, Ribbed
54 88681 1 CARD, Owner Registration
55 85883 1 STA-BIL
56 BB3061B 1 OIL
57 83831 1 BROCHURE, Stabil
58 81886 1 DECAL, Stabil
59 B4099 1 DECAL, IMP. Purge Air
60 95458 1 QUICK DISCONNECT, Hose
to Gun
PARTS LIST PRESSURE WASHER
Generac Portable Products 2300PSI High Pressure Washer
