Maintenance
24 Owner’s Manual for 60 Hz EcoGen™ Generator
Changing the Oil and Oil Filter
Figure 4-3. Exploded View – EcoGen Oil System Drain Pump Kit
An Oil System Drain Pump Kit (P/N 0K3717) has been
shipped with this unit. Refer to the instructions included
with that kit for assembly and use of the Oil System Drain
Pump. If the Oil System Drain Pump has become lost, or
is unavailable, use a suitable suction pump to perform
the following oil change procedure.
EcoGen Oil System Drain Pump Kit Parts List
(Kit Part No. 0K3717)
EcoGen Oil System Drain Pump Assembly
1. See Figure 4-4. Install the ¼ in. Hose Assembly
onto the inlet side of the Drill Pump. Twist the fitting
clockwise until it is snug. Do not over-tighten.
Figure 4-4. Pump Assembly Step 1
2. See Figure 4-5. Install the ½ in. Hose Assembly
onto the outlet side of the Drill Pump. Twist the
fitting clockwise until it is snug. Do not over-tighten.
Figure 4-5. Pump Assembly Step 2
A ¾ in. Spring Clamp**
B ½ in. Rubber Hose**
C ½ in. Barb Hose Fitting with ¾ in. Hose Thread**
D Drill Pump
E ¼ in. Barb Hose Fitting w/¾ in. Hose Thread*
F ½ in. Spring Clamp*
G ¼ in. Rubber Hose*
* Parts 1, 2, and 6 come assembled from the supplier.
** Parts 3, 4, and 7 come assembled from the supplier.
