Generac Power Systems 15 kW EcoGen - Section 6 Installation Diagrams; Installation Drawing

Installation Diagrams
Owner’s Manual for 60 Hz EcoGen™ Generator 37
Section 6 Installation Diagrams
Installation Drawing
914 [36.0]
MINIMUM OPEN AREA
ON SIDES AND FRONT
457.2
[18.0]
76.2 [3.0]
PEA GRAVEL
MINIMUM
1229.5 [48.4]
1226 [48.3]
732.5 [28.8]
637.6 [25.1]
642 [25.3]
300.4 [11.8]
179.0 [7.0]
560.0 [22.0]
353.7 [13.9]
1154.0 [45.4]
446.6 [17.6]
389.7 [15.3]
36.0 [1.4]
44.8 [1.8]
LEFT SIDE VIEW
REAR VIEW
"DO NOT LIFT BY ROOF"
**ALL DIMENSIONS IN: MILLIMETERS [INCHES]
A CONCRETE PAD
OPTIONAL MOUNTING TO
HOLE LOCATIONS FOR
TOP VIEW
16.0 [5/8] DIA. CLEARANCE
HOLE (2) PLACES,
3/8 DIA. MASONRY ANCHOR
BOLTS RECOMMENDED
AIR INTAKE
AIR OUTLET
AIR INTAKE
FUEL INLET - 15KW (1/2" NPT) REQUIRED FUEL PRESSURE: NATURAL GAS : 3.5-7" WATER COLUMN LIQUID PROPANE (VAPOR) : 10-12" WATER COLUMN
GROUND LUG
GROUND STUD
CABLE ACCESS HOLE
FRONT VIEW
RIGHT SIDE VIEW
FRONT OF UNIT
10.0 [3/8] DIA. CLEARANCE
HOLE (2) PLACES,
3/8 DIA. MASONRY ANCHOR
BOLTS RECOMMENDED
A CONCRETE PAD
OPTIONAL MOUNTING TO
HOLE LOCATIONS FOR
30.2 [ 1.2]
LIFTING HOLES 4 CORNERS
