Troubleshooting / Diagnostics

36 Owner’s Manual for 60 Hz EcoGen™ Generator

G-Flex™ Diagnostics

Table 5-4. G-Flex™ Diagnostics

Symptom Possible Causes

Generator stalls when large load is

supplied.

Total load is too big for the generator. Loads must be less than 10 kW or 2 hp when

operating under 3600 rpm.Contact installing dealer to correct installation.

Output voltage is low/high. Voltage calibration incorrect. Contact servicing dealer.

Generator does not pull full power. Current calibration incorrect. Contact servicing dealer.
