ITEM PART NO. QTY. DESCRIPTION
1 070023 1 CONTROL PANEL BOTTOM
2 070026 1 SLKSCRND PANEL FRONT
3 070028 1 COVER CON PNL SIDE
4 067680 1 ASSY VOLTAGE REGULATOR 60HZ
092952 1 ASSY VOLTAGE REGULATOR 50HZ
5 039271 1 FITTING 90 DEGREE 3/4
6 034616 1 FITTING STRAIGHT 3/4
7 1 CIRCUIT BREAKER
8 082985 1 RES 100R 5% 5W ASSY=55405
9 082984 1 RES 120R 10% 2W ASSY 55406
10 086266 1 RES WW LUG 75R 5% 25W
11 055444 1 HEATSINK
12 030468 1 WASHER STEP NYLON .20
13 049939 1 RECTIFIER MSC 12A 600V 1N1206R
14 083089 1 ASSY PCB "C" CONTROL 12/24V
15 033147 1 SCREW HHM #10-32 X 1
16 024469 2 SCREW HHTT #10-32 X 3/8 CZ_
17 084853A 1 HARNESS F/<100KW 24V C DIESEL
084853B 1 HARNESS F/>101KW 24V C DIESEL
084853C 1 HARNESS F/12LMITS 24V C DIESEL
18 029333 6 TIE WRAP 7.4"X.19" NATL UL
19 084875 1 DECAL TERMINAL STRIP
20 055920 1 SWITCH SPST SPADE PNL MNT
21 055867 1 SWITCH TOG SPDT 15A SPD MOM
22 067625 1 SWITCH TOGGLE 3P3T 15/10A
23 032300 1 HOLDER FUSE
24 022676 1 FUSE 15A X AGC15
25 040213 4 PCB SUPPORT SNAP-IN 1/4"
26 0C2428 14 SCREW PHTT #6-32 X 1/2 ZYC
27 061945 1 SWITCH SELECTOR 6A AMP/V
28 071361 1 POT 5K 10% 2.25W PNL
29 050123 1 KNOB PLASTIC .25 SHAFT
30 055349 1 INSULATOR
31 070030 1 COVER GENERAC SILKSCREENED
33 070042 1 FREQUENCY METER 240V 55-65HZ
070042-A 1 FREQUENCY METER 240V 45-55HZ
34 1 AC AMMETER
35 1 AC VOLTMETER
36 083287 1 LIGHT HLDR CLR LNS W/O BULB
ITEM PART NO. QTY. DESCRIPTION
37 070081 1 HOURMETER
38 062304 1 AMMETER 40-0-40 DC
39 055405 1 GAUGE OIL PRESSURE
40 055406 1 GAUGE COOLANT TEMPERATURE
41 070083 1 ASSY PCB ENGINE MONITOR
42 055089 1 CONN PLUG PNL 15P AMP M-N-L
43 070082 1 BLOCKER LIGHT
44 053247 1 LUG RNGTNG INS 22-18 X10 X.322
45 029187 2 SPACER .19 X .31 X .50 PL
46 077043B 1 FLEX CONDUIT .50 ID
50 036904 4 SCREW PPHM #6-32 X 3/4 (NOT SHOWN)
51 036908 2 SCREW PPHM #6-32 X 1-1/4
52 022155 2 WASHER LOCK #6
53 022985 6 WASHER FLAT #6 ZINC
54 022188 2 NUT HEX #6-32 STEEL
55 036918 4 SCREW PPHM #8-32 X 1/2
56 022264 4 WASHER LOCK #8-M4
57 033121 16 SCREW HHC #10-32 X ½
58 022152 26 WASHER LOCK #10
59 023897 14 WASHER FLAT #10 ZINC
60 022158 20 NUT HEX #10-32 STEEL
61 038150 4 WASHER FLAT #8 ZINC
62 022471 4 NUT HEX #8-32 STEEL
63 084787 1 CABLE RIBBON 16"
64 070370 2 WASHER MICA .203
65 083288 1 LIGHT 28VDC .17A MIN BAYNT MNT
66 023762 4 WASHER SHAKEPROOF EXT #10 STL
68 081767 2 RELAY PNL 24VDC DPDT 10A
70 064000 1 CONTROL PNL SIDE
71 064008 1 COVER CON PNL TOP
72 098940 1 HARNESS C-OPT CTRL PNL
73 066040 1 DECAL - TERM STRIP
77 0C2323 4 SCREW PHTT #6-32 X 5/8 ZYC
78 0C1229 1 DECAL CUST CONN BOX
79 022507 4 SCREW HHC 1/4-20 X 1/2 G5 (NOT
SHOWN)
80 022097 8 WASHER LOCK M6-1/4 (NOT SHOWN)
81 040479 4 VIB MNT 1.0 X 1.0 X 1/4-20 (NOT SHOWN)
Appendix 2 — Exploded Views and Parts Lists
“C” Option Control Panel 24 Volt Diesel
Control Panel – Drawing No. 84851-J

Generac Power Systems C Option Specifications

General

Brand	Generac Power Systems
Model	C Option
Category	Control Panel
Language	English
