Section 1 — General Information
Remote Annunciator Panels
3. Latch Select: The lamps and horn can be selected
to be latched by on-board switch. Unlatched signals
activate the lamp only; the lamp is de-energized if
the fault signal is cleared. Latching provides an
audible signal plus keeps the lamp energized as an
indicator even if the pre-alarm fault has been
cleared.
4. Rearm: The rearm clears the horn but not the
lamps. The lamps are held active by either latch or
fault signal. After rearm, horn is enabled to sound if
another fault occurs.
5. System Ready Lamp: This lamp indicates the
genset is operational. The lamp is energized when-
ever power is applied to the annunciator circuit and
no generator stop signals are present.
6. Line-Power/Gen Power Lamps: This indicates the
position of the transfer switch. When load is trans-
ferred to the genset, the “Generator Power” lamp is
lit and the horn sounds.
7. Horn Switch Off Lamp: This lamp indicates that
power to the horn has been disconnected by a horn
disable switch.
8. Annunciator Delays: Signals will be annunciated if
the exist for the following minimum times:
• Not in Auto, Horn Off, 100 seconds.
• Pre-alarm Low Oil Pressure, 10 seconds.
• All others, 1 second.
Signal Source Lamp Response Latched Rearm
High Temp. Control Board* Red Lamp & Horn Yes Yes
Low Oil Control Board* Red Lamp & Horn Yes Yes
Overspeed Control board* Red Lamp & Horn Yes Yes
Overcrank Control Board* Red Lamp & Horn Yes Yes
Sensor Loss Control Board* Red Lamp & Horn Yes Yes
System Ready Annunciator Green Lamp No N/A
Line Power Transfer Switch Green Lamp No N/A
Generator Power Transfer Switch Yellow Lamp & Horn No Yes
High Battery Battery Monitor Yellow Lamp & Horn Select Yes
Low Battery Battery Monitor Yellow Lamp & HOrn Select Yes
Not In Auto Control Board Red Lamp & Horn No No
Horn Switch Off Annunciator Red Lamp No N/A
Signal Source Lamp Response Latched Rearm
Low Fuel Float Switch Yellow Lamp & Horn Select Yes
High Temperature Temperature Switch Yellow Lamp & Horn Select Yes
Low Temperature Temperature Switch Yellow Lamp & Horn Select Yes
Low Oil Pressure Switch Yellow Lamp & Horn Select Yes
Generator Run Control Board Yellow Lamp & Horn Select Yes
Battery Charge Fail Battery Monitor Yellow Lamp & Horn Select Yes
1.5 ANNUNCIATED SIGNALS
1.6 PRE-ALARMS
