ITEM PART NO. QTY. DESCRIPTION
1 070023 1 CONTROL PANEL BOTTOM
2 070026 1 CONTROL PANEL FRONT
3 070028 1 CONTROL PANEL SIDE
4 067680 1 REGULATOR ASSEMBLY VOLTAGE B&D
5 039271 1 FITTING 90 DEGREE 3/4
6 034616 1 FITTING STRAIGHT 3/4
7 057159 1 CIRCT BRK 2 X 1 ETA 46-500-P
053623 1 CIRCT BRK 2.5 X 1 ETA 46-500-P
054502 1 CIRCT BRK 3 X 1 ETA 46-500-P
056247 1 CIRCT BRK 3.5 X 1 ETA 46-500-P
049350 1 CIRCT BRK 4 X 1 ETA 46-500-P
048476 1 CIRCT BRK 4.5 X 1 AUT30KW CNT45K
048512 1 CIRCT BRK 5 X 1 ETA 46-500-P
054450 1 CIRCT BRK 5.5 X 1 ETA 46-500-P
048505 1 CIRCT BRK 6 X 1 ETA 46-500-P
048467 1 CIRCT BRK 7 X 1 ETA 46-500-P
048468 1 CIRCT BRK 8 X 1 ETA 46-500-P
048470 1 CIRCT BRK 9 X 1 ETA 46-500-P
8 057335 1 BLOCK TERM 20A 20 X 6 X 1100V
9 046669 7 BLOCK TERM JUMPER FOR S141
10 ** 081767 1 RELAY PNL 24VDC DPDT 10A
11 070042 1 METER FREQUENCY 55-65HZ
070042A 1 METER FREQUENCY 240V 45-55HZ
12 070054 1 AMMETER AC 0 TO 50
070055 1 AMMETER AC 0 TO 100
070056 1 AMMETER AC 0 TO 150
070045 1 AMMETER AC 0 TO 200
070057 1 AMMETER AC 0 TO 300
070058 1 AMMETER AC 0 TO 400
070059 1 AMMETER AC 0 TO 600
070060 1 AMMETER AC 0 TO 800
13 070043 1 METER VOLT AC 0-300
070044 1 METER VOLT AC 0-600
14 083089 1 ASSY BOARD "C" CONTROL 12/24V
15 0C2428 8 SCREW TAPTITE PH #6-32 X 1/2 ZYC
17 064000 1 CONTROL PANEL SIDE
18 064008 1 COVER CONTROL PANEL TOP (NOT
SHOWN)
19 084736 1 DECAL TERMINAL STRIP
20 026536 1 PLUG STEEL 0.5
21 055867 1 SWITCH SPDT 15A SPD TGGL MOM
22 067625 1 SWITCH 3P TRIP THR 15/10A TGGL
23 032300 1 HOLDER FUSE
24 022676 1 FUSE 15A X AGC15
25 040213 4 PCB SUPPORT SNAP-IN 1/4
26 024469 2 SCREW TAPTITE #10-32 X 3/8 BP
27 061945 1 SWITCH 6A AMP/V SELECTOR
28 071361 1 POTENTIOMETER 5K +/-10% 2.25W PNL
29 050123 1 KNOB PLASTIC .25 SHAFT
30 055349 1 INSULATOR
31 070030 1 COVER GENERAC SILKSCREEN
ITEM PART NO. QTY. DESCRIPTION
32 * 084717 1 ASSEMBLY TIME RELAY
33 084733 1 HARNESS CONTROL PANEL C
34 083287 1 LIGHT HLDR CLR LNS W/O BULB
35 083288 1 LIGHT 28V DC .17A MIN BAYNT MNT
37 070081 1 METER HOURS
38 062304 1 AMMETER 40-0-40 DC
39 055405 1 GAUGE OIL PRESSURE
40 055406 1 GAUGE COOLANT TEMPERATURE
41 066040 1 DECAL TERMINAL STRIP
42 055089 1 CONN ELEC AMP M-N-L 15 PLUG PNL
43 070082 1 BLOCKER LIGHT
44 053247 1 LUG RNGTNG INS 22-18 X 10 X .322
45 029187 2 SPACER .19 X .31 X .50 ST/ZNC
46 077043B 16" FLEX CONDUIT .50 ID
47 029333 6 TIE WRAP 7" WHITE
49 0C2323 10 SCREW PHM SWAGE 6-32 X 5/8 Z/YC
50 036904 2 SCREW PPHM #6-32 X 3/4 (NOT SHOWN)
51 036908 2 SCREW PPHM #6-32 X 1-1/4
52 022155 2 WASHER LOCK #6
53 022985 6 WASHER FLAT #6-M4
54 022188 2 NUT HEX #6-32 STEEL
55 036918 4 SCREW PPHM #8-32 X 1/2
56 022264 11 WASHER LOCK M4
57 033121 14 SCREW HHM 10-32 X 1/2
58 022152 22 WASHER LOCK #10
59 023897 15 WASHER FLAT #10 ZINC
60 022158 11 NUT HEX #10-32 STEEL
61 038150 8 WASHER FLAT #8 ZINC
62 022471 4 NUT HEX #8-32 STEEL
63 084787 1 CABLE RIBBON 16"
64 070083 1 ASSEMBLY ENGINE MONITOR
65 082985 1 ASSEMBLY RESISTER 68 OHM 5W
66 082984 1 ASSEMBLY RESISTER 120 OHM 2W
67 098940 1 HARNESS C-OPT CTRL PNL
69 023762 3 WASHER SHAKEPROOF EXT #10 STL
70 055444 1 SINK HEAT
71 030468 1 WASHER STEP NYLON .20
72 049939 1 RECTIFIER MSC 12A 600V 1N1206R
73 070370 2 WASHER MICA .203
75 086266 1 RESISTOR WW LUG 75R 5% 25W
76 022507 4 SCREW HHC 1/4-20 X 1/2 G5 (NOT
SHOWN)
77 022097 8 WASHER LOCK M6-1/4 (NOT SHOWN)
78 040479 4 MOUNT VIBR 1.0 X 1.0 X 1/4-20 (NOT
SHOWN)
79 0441140156 1 WIRE ASSY 18AWG #0 (NOT SHOWN)
80 033147 1 SCREW HHM #10-32 X 1 (NOT SHOWN)
81 0C1299 1 DECAL WARNING
* USED ON 13.3L SPARK IGNITED ONLY
** USED ON 13.3L TURBO SPARK ONLY
Appendix 2 — Exploded Views and Parts Lists
“C” Option Control Panel 24 Volt Gas
Control Panel – Drawing No. 84711-N
