Generac Power Systems C Option User Manual

Generac
®
Power Systems, Inc. 21
ITEM PART NO. QTY. DESCRIPTION
1 070023 1 CONTROL PANEL BOTTOM
2 070026 1 CONTROL PANEL FRONT
3 070028 1 CONTROL PANEL SIDE
4 067680 1 REGULATOR VOLT 60HZ
092952 1 REGULATOR VOLT 50HZ
5 039271 1 FITTING 90 DEGREE 3/4
6 034616 1 FITTING STRAIGHT 3/4
7 057159 1 CIRCT BRK 2 X 1 ETA 46-500-P
053623 1 CIRCT BRK 2.5 X 1 ETA 46-500-P
054502 1 CIRCT BRK 3 X 1 ETA 46-500-P
056247 1 CIRCT BRK 3.5 X 1 ETA 46-500-P
049350 1 CIRCT BRK 4 X 1 ETA 46-500-P
048476 1 CIRCT BRK 4.5 X 1 AUT 30KW CNT45K
048512 1 CIRCT BRK 5 X 1 ETA 46-500-P
054450 1 CIRCT BRK 5.5 X 1 ETA 46-500-P
048505 1 CIRCT BRK 6 X 1 ETA 46-500-P
048467 1 CIRCT BRK 7 X 1 ETA 46-500-P
048468 1 CIRCT BRK 8 X 1 ETA 46-500-P
048470 1 CIRCT BRK 9 X 1 ETA 46-500-P
8 044213 1 RESIST MISC 10R X 12W
9 025192 1 RECTIFIER MSC 2A 600V 1N5062
10 048352 1 RESIST MISC 5R X 25W
057907 1 RESISTOR WW LUG 10R 10% 25W
057405 1 RESIST MISC 25R X 25W
11 055444 1 HEAT SINK 13.3L
12 030468 1 WASHER STEP NYLON .20
13 049939 1 RECTIFIER MSC 12A 600V 1N1206R
14 083089 1 BOARD "C" CONTROL 12/24V
15 024469 2 SCREW TAPTITE #10-32X3/8 BP
17 085058 1 HARNESS 12 VOLT DIESEL
18 029333 6 TIE WRAP 7" WHITE
19 070097 1 DECAL TERMINAL STRIP
20 055920 1 SWITCH 1PST PSADE PNL MNT
21 055867 1 SWITCH SPDT 15A SPD TGGL MOM
22 067625 1 SWITCH 3P TRIP THR 15/10A TGGL
23 032300 1 HOLDER FUSE
24 022676 1 FUSE 15A X AGC15
25 040213 4 CONN PCB SUP SNAP-IN
26 0C2428 8 SCREW TAPTITE PH #6-32 X 1/2 ZYC
27 061945 1 SWITCH 6A AMP/V SELECTOR
28 071361 1 POTENTIO PNL 5K +/-10% 2.25W
29 050123 1 KNOB PLASTIC .25 SHAFT
30 055349 1 INSULATOR
31 070030 1 COVER SILKSCREEN
32 070080 2 INSULATOR
33 070042 1 METER FREQUENCY 55-65HZ
070042A 1 METER FREQUENCY 240V 45-55HZ
34 070054 1 AMMETER AC 0 TO 50
070055 1 AMMETER AC 0 TO 100
070056 1 AMMETER AC 0 TO 150
070045 1 AMMETER AC 0 TO 200
ITEM PART NO. QTY. DESCRIPTION
070057 1 AMMETER AC 0 TO 300
070058 1 AMMETER AC 0 TO 400
070059 1 AMMETER AC 0 TO 600
070060 1 AMMETER AC 0 TO 800
35 070043 1 METER VOLT AC 0 TO 300
070044 1 METER VOLT AC 0 TO 600
36 070202 1 LIGHT PANEL
37 070081 1 METER HOURS
38 062304 1 AMMETER 40-0-40 DC
39 055405 1 GAUGE OIL PRESSURE
40 055406 1 GAUGE COOLANT TEMPERATURE
41 070083 1 ASSY ENGINE MONITOR
42 055089 1 CONN ELEC AMP M-N-L 15PLUG PNL
43 070082 1 BLOCKER LIGHT
44 053247 1 LUG RNGTNG INS 22-18 X 10 X .322
45 029187 2 SPACER .19 X .31 X .50 ST/ZNC
46 077043B 16" FLEX CONDUIT .50 ID
49 0C2323 12 SCREW PHM SWAGE 6-32X5/8 Z/YC
51 036908 2 SCREW PPHM #6-32 X 1-1/4
52 022155 2 WASHER LOCK #6
53 022985 2 WASHER FLAT #6
54 022188 2 NUT HEX #6-32 STEEL
55 036918 4 SCREW HHM #8-32 X 1/2
56 022264 6 WASHER LOCK M4
57 033121 14 SCREW HHM 10-32 X 1/2
58 022152 20 WASHER LOCK #10
59 023897 12 WASHER FLAT #10
60 022158 9 NUT HEX #10-32 STEEL
61 038150 4 WASHER FLAT #8 ZINC
62 022471 4 NUT HEX #8-32 STEEL
63 084787 1 CABLE RIBBON 16"
64 070370 2 WASHER MICA .203
65 063617 1 RELAY PNL 12VDC DPDT 10A @ 240VA
66 023762 1 WASHER SHAKEPROOF EXT #10 STL
67 057335 1 BLOCK TERM 20A 20 X 6 X 1100V
68 046669 5 JUMPER TERMINAL BLOCK
69 098940 1 HARNESS C-OPTION CONTROL PANEL
70 064000 1 SIDE CONTROL PANEL
71 064008 1 COVER CONTROL PANEL TOP
(NOT SHOWN)
72 066040 1 DECAL TERMINAL STRIP
73 022507 4 SCREW HHC 1/4-20 X 1/2 G5
(NOT SHOWN)
74 022097 8 WASHER LOCK M6-1/4 (NOT SHOWN)
75 040479 4 MOUNT VIBR 1.00X1.00X1/4-20
(NOT SHOWN)
76 036904 2 SCREW PPHM #6-32 X 3/4
(NOT SHOWN)
77 0441140156 1 ASSY WIRE 18AWG #15 (NOT SHOWN)
78 033147 1 SCREW HHM #10-32 X 1 (NOT SHOWN)
Appendix 2 — Exploded Views and Parts Lists
“C” Option Control Panel 12 Volt Diesel
Control Panel – Drawing No. 85027-H
