Appendix 4 — Electrical Data
Five Light Remote Annunciator
Electrical Schematic – Drawing No. 066561
Leg
end
L1 = Low Oil Pressure Lamp L2 = High Coolant Temperature Lamp L3 = Overcrank Lamp L4 = Overspeed Lamp L5 = RPM Sensor Loss Lamp SW1 = Reset Switch SW2 = Test Switch H1 = Alarm Horn
