Controller Operation
Fault Description
Calibration Fault The module detected that its internal calibration has failed. The
unit must be sent back to DSE to be investigated and repaired.
Contact DSE Technical Support for more details.
Charge Alt Failure
IEEE 37.2 – 27 DC Undervoltage Relay
The module detected that the output voltage of the charge alter-
nator had fallen below the Charge Alternator Warning Trip level
for the configured delay timer.
Charger Fan Locked The module detected that a battery charger connected by DSE-
Net® had a Charger Failure alarm.
Charger High Temperature The module detected that a battery charger connected by DSE-
Net® had a High Temperature alarm.
Charger Mains High Current The module detected that a battery charger connected by DSE-
Net® had a Mains High Current alarm.
Charger ID 0 to 3 Common Warning
NOTE: Due to module configuration the alarm message that ap-
pears on the display may be different. For further details of mod-
ule configuration, contact your Authorized Industrial Service
Dealer (IASD).
The module detected that a battery charger connected by DSE-
Net® had issued a Common Warning Alarm.
Charger Mains High Voltage The module detected that a battery charger connected by DSE-
Net® had a Mains High Voltage alarm.
Charger Mains Low Voltage The module detected that a battery charger connected by DSE-
Net® had a Mains Low Voltage alarm.
Charger Voltage Drop Charging Cable Output 1 The module detected that a battery charger connected by DSE-
Net® had issued a Voltage Drop Charging Cable alarm on its
Output 1.
Charger Voltage Drop Charging Cable Output 2 The module detected that a battery charger connected by DSE-
Net® had issued a Voltage Drop Charging Cable alarm on its
Output 2.
Coolant Temp High
IEEE C37.2 – 26 Apparatus Thermal Device
The module detected that the engine coolant temperature had
risen above the High Coolant Temperature Pre-Alarm Trip level
after the Safety On Delay timer had expired.
DEF Level Low The module received a fault condition from the engine ECU
alerting about the DEF level.
Coolant Temp High
IEEE C37.2 – 26 Apparatus Thermal Device
The module detected that the engine coolant temperature had
risen above the High Coolant Temperature Pre-Alarm Trip level
after the Safety On Delay timer had expired.
Digital Input A to L
NOTE: Due to module configuration the alarm message that ap-
pears on the display may be different. For further details of mod-
ule configuration, contact your Authorized Industrial Service
Dealer (IASD).
The module detected that a digital input configured to create a
fault condition became active and the appropriate LCD mes-
sage is displayed.
DPTC Filter The module received a fault condition from the engine ECU
alerting that the DPF/DPTC had activated.
Earth Fault
IEEE C37.2 – 51G or 51N
Deep Sea Electronics® G8601 Controller Owner’s Manual 13
