Controller Operation
Fault Description
The module detects a condition that indicates the generator is
running when the DSE module has instructed it to stop.
Fuel Sensor Fault The module detected that circuit to the engine fuel level sensor
had become open circuit.
Gen Over Frequency
IEEE C37.2 – 81 Frequency Relay
The module detected that the generator output frequency had
risen above the Over Frequency Alarm Trip level for the config-
ured delay timer.
Gen Over Frequency Overshoot
IEEE C37.2 – 81 Frequency Relay
The module detected that the generator output frequency had
risen above the Over Frequency Overshoot Trip during the con-
figured Overshoot Delay timer whilst starting.
Gen Over Voltage
IEEE C37.2 – 59 AC Overvoltage Relay
The module detected that the generator output voltage had ris-
en above the Over Voltage Alarm Trip level for the configured
delay timer.
Gen Phase Seq Wrong
IEEE C37.2 – 47 Phase Sequence Relay
The module detected that the phase rotation of the generator
was different to the configured Generator Phase Rotation Alarm
setting.
Gen Reverse Power
IEEE C37.2 – 32 Directional Power Relay
The module detected that the generator output kW had fallen
below the Reverse Power Trip for the configured delay timer.
Gen Short Circuit
IEEE C37.2 – 51 IDMT Short Circuit Relay The module detected that the generator output current had ris-
en above the Short Circuit Trip for the duration of the IDMT
function.
Gen Under Frequency
IEEE C37.2 – 81 Frequency Relay
The module detected that the generator output frequency had
fallen below the Under Frequency Alarm Trip level for the con-
figured delay timer after the Safety On Delay timer had expired.
Gen Under Voltage
IEEE C37.2 – 27 AC Undervoltage Relay
The module detected that the generator output voltage had fall-
en below the Under Voltage Alarm Trip level for the configured
delay timer after the Safety On Delay timer had expired.
Mag-PU Fault The module detected that circuit to the magnetic pick up sensor
had become open circuit.
Oil Press Sender Fault The module detected that circuit to the engine oil pressure sen-
sor had become open circuit.
Oil Pressure Low
IEEE C37.2 - 63 Pressure Switch
The module detected that the engine oil pressure had fallen be-
low the Low Oil Pressure Shutdown Trip level after the Safety
On Delay timer had expired.
Oil Pressure Low Switch
IEEE C37.2 - 63 Pressure Switch
The module detected that the low oil pressure switch had acti-
vated after the Safety On Delay timer had expired.
Temp. Sender Fault The module detected that circuit to the engine coolant tempera-
ture sensor had become open circuit.
Adding New Language Files
The DSE Configuration Suite PC Software and DSE Con-
trol modules are able to have their default languages
changed to suit the end user.
Obtain Files
The files are either obtained from the Deep Sea Elec-
tronics Technical Support Department, contact your Au-
thorized Industrial Service Dealer (IASD).
Deep Sea Electronics® G8601 Controller Owner’s Manual 23
