General Information
Specifications
Supply
Minimum Supply Voltage 5 VDC continuous
Cranking Dropouts Able to survive 0 VDC for 100 ms, provided supply was at least
15 VDC for 2 seconds before the dropout and recovers to 5
VDC afterwards.
Maximum Supply Voltage 35 VDC continuous (60 VDC protection)
Reverse Polarity Protection -35 VDC continuous
Maximum Operating Current 700 mA at 12 VDC
350 mA at 24 VDC
Maximum Standby Current 350 mA at 12VDC
190 mA at 24 VDC
Maximum Current When In Sleep Mode 110 mA at 12 VDC
60 mA at 24 VDC
Typical Power
(Controller On, Heater Off)
4.0 W to 4.5 W
Typical Power
(Controller On, Heater On)
4.5 W to 11 W
Generator and Bus
Voltage Range 25 V to 720 VAC (Phase to Phase)
Frequency Range 3.5 Hz to 75 Hz
Current Range 5 A Maximum Continuous Current
Magnetic Pickup
Voltage Range +/- 0.5 VDC to 70 VDC RMS
Frequency Range 5 Hz to 10,000 Hz RMS
Inputs
Digital Inputs 16 Configurable Inputs
Analog Inputs 7 Configurable Inputs
Outputs Current Limit
Output A & B (Fuel & Start) 15 A DC supplied from E-Stop (total A+B Max 15 A)
Output C & D 8 A Resistive at 250 V AC
Auxiliary Outputs E to L 2 A Resistive at supply voltage
Temperature
Storage Temperature Range -40 °C to +85 °C / -40 °F to +185 °F
Operating Temperature w/o display heater -30 °C to +70 °C/ -22 °F to +158 °F
Operating Temperature w/ display heater -40 °C to +70 °C / -40 °F to +158 °F
8 Deep Sea Electronics® G8601 Controller Owner’s Manual
