Generac Power Systems Deep Sea Electronics G8601 User Manual

Controller Operation
Fault Description
Fuel Level Low
IEEE C37.2 - 71 Liquid Level Switch
The module detected that the engine fuel level had fallen below
the Low Fuel Level Pre-Alarm level for the configured delay.
Fuel Level Low Switch
IEEE C37.2 - 71 Liquid Level Switch
The module detected that the engine low fuel level switch had
activated.
Fuel Tank Bund Level High
IEEE C37.2 - 71 Liquid Level Switch
The module detected that the fuel tank bund level switch had
activated.
Fuel Usage
IEEE C37.2 – 80 Flow Switch
The module detected that the fuel consumption was more than
the configured Running Rate or Stopped Rate.
Gen Earth Fault
IEEE C37.2 – 51G or 51N Generator IDMT
Earth Fault Relay
The module detected that the generator earth fault current had
risen above the Earth Fault Trip Level for the duration of the
IDMT function.
Gen Failed to Open
IEEE C37.2 – 52b AC Circuit Breaker Position
(Contact Open when Breaker Closed)
The module detected that the Generator Load Switch has not
Opened after being commanded to Open.
Gen Loading Frequency The module detected that the generator output frequency had
not risen above the Generator Loading Frequency setting after
the Warming Up timer had expired.
Gen Loading Voltage The module detected that the generator output voltage had not
risen above the Generator Loading Voltage setting after the
Warming Up timer had expired.
Gen Over Current
IEEE C37.2 – 50 Instantaneous Overcurrent Relay
IEEE C37.2 – 51 IDMT Overcurrent Relay
The module detected that the generator output current had ris-
en above the Generator Over Current Trip.
Gen Over Frequency
IEEE C37.2 – 81 Frequency Relay
The module detected that the generator output frequency had
risen above the Over Frequency Pre-Alarm Trip level for the
configured delay timer.
Gen Over Frequency Delayed
IEEE C37.2 – 81 Frequency Relay
The module detected that the generator output frequency had
risen above the Over Frequency Trip level but was below the
Over Frequency Overshoot Trip for the configured Overshoot
Delay timer during starting.
Gen Over Voltage
IEEE C37.2 – 59 AC Overvoltage Relay
The module detected that the generator output voltage had ris-
en above the Over Voltage Pre-Alarm Trip level for the config-
ured delay timer.
Gen Reverse Power
IEEE C37.2 – 32 Directional Power Relay
The module detected that the generator output kW had fallen
below the Reverse Power Trip for the configured delay timer.
Gen Short Circuit
IEEE C37.2 – 51 IDMT Short Circuit Relay The module detected that the generator output current had ris-
en above the Short Circuit Trip for the duration of the IDMT
function.
Gen Under Frequency
IEEE C37.2 – 81 Frequency Relay
The module detected that the generator output frequency had
fallen below the Under Frequency Pre-Alarm Trip level for the
configured delay timer after the Safety On Delay timer had
expired.
Gen Under Voltage
IEEE C37.2 – 27 AC Undervoltage Relay
The module detected that the generator output voltage had fall-
en below the Under Voltage Pre-Alarm Trip level for the config-
ured delay timer after the Safety On Delay timer had expired.
HEST Active The module received a fault condition from the engine ECU
alerting that the HEST had activated.
Deep Sea Electronics® G8601 Controller Owner’s Manual 15
