Controller Operation
7 1.0 mm²
AWG 18
DC Output E
8 1.0 mm²
AWG 18
DC Output F
9 1.0 mm²
AWG 18
DC Output G
10 1.0 mm²
AWG 18
DC Output H
11 1.0 mm²
AWG 18
DC Output I
12 1.0 mm²
AWG 18
DC Output J
13 1.0 mm²
AWG 18
DC Output K
14 1.0 mm²
AWG 18
DC Output L
15 0.5 mm²
AWG 20
Sensor Common Return for
Analog Sensor Inputs A,B,C,D
16 0.5 mm²
AWG 20
Analog Sensor Input A
17 0.5 mm²
AWG 20
Analog Sensor Input B
18 0.5 mm²
AWG 20
Analog Sensor Input C
19 0.5 mm²
AWG 20
Analog Sensor Input D
CAN
REDUNDANT
AMSC 2
(MULTISET ONLY)
20 0.5 mm²
AWG 20
CAN Port H
21 0.5 mm²
AWG 20
CAN Port L
22 Shield CAN Port Screen
23 0.5 mm²
AWG 20
Magnetic Pickup Positive
24 0.5 mm²
AWG 20
Magnetic Pickup Negative
25 Shield Magnetic Pickup Screen
CAN 1
26 0.5 mm²
AWG 20
ECU Port H
27 0.5 mm²
AWG 20
ECU Port L
28 Shield ECU Port Screen
29 0.5 mm²
AWG 20
DSENet® Expansion B
30 0.5 mm²
AWG 20
DSENet® Expansion A
31 Shield DSENet® Expansion Screen
26 Deep Sea Electronics® G8601 Controller Owner’s Manual
