MEGAFORCE 6500 Extended Life Generator
19
Item Part # Qty Description
1 B92432 1 CRADLE
2 B92531 1 SUPPORT, Engine
3 B92731 1 SUPPORT, Engine & Muffler
4 92247 1 HOUSING, Engine Adapter
5 92679G 1 ASSEMBLY, Rotor
6 92681G 1 ASSEMBLY, Stator
7 65791 1 BEARING
8 67451 1 WASHER, M8 Flat
9 22129 14 WASHER, M8 Lock
10 86307 4 SCREW, 5/16-24 x 3/4 Mach.
11 25254 1 SCREW, 5/16-24 x 9-7/8"
12 92609 2 MOUNT, Vibration
13 82857 4 MOUNT, Vibration
14 40976 2 SCREW, M8 - 1.25 x 20
15 66476 2 CAPSCREW, M6 - 1.0 x
12mm
16 92532 1 BRACKET, Muffler
17 22142 2 SCREW, 5/16 - 18 x 3/4"
18 91153 1 MUFFLER
19 90239 1 GASKET, Muffler
20 81917 1 PIN, 4 mm x 10 Roll
24 83083 1 SCREEN, Spark Arrest
25 66825C 1 CARRIER, Rear Bearing
26 74908 4 SCREW, M5-0.8 x 10 Taptite
27 86308B 4 BOLT, M6-1 x 165mm Stator
28 65795 1 RECTIFIER, Battery Charge
29 66849A 1 SCREW, M5-0.8 x 20 Taptite
30 67022 1 GROMMET, Rubber
31 84132 1 ASSEMBLY, Power Regulator
32 66386 1 ASSEMBLY, Brush Holder
33 66849 2 SCREW, M5-0.8 x 16 Taptite
34 B67025 1 COVER, Bearing Carrier
35 22769 1 WASHER, #10 Int.
Shakeproof
36 86494 1 SCREW, M6-1.0 x 16 Wing
37 86292 7 SCREW, #10 Self Drilling
38 77395 4 NUT, M6 Flange Lock
39 83465 4 GROMMET, Tank
40 57058 4 HHCS, M6-1.0 x 55
Item Part # Qty Description
41 80270 1 VALVE, Tank
42 78299 1 BUSHING, Plastic Tank
43 B4363 1 CAP, Fuel Gauge
44 B1695 1 TANK, Fuel 7-Gal
45 B92039 1 SHIELD, Heat
46 92665 1 INSULATION, #2-1/4"
47 85000 1 CLIP, Insulation
48 14353621 1 WIRE, Ground
49 26850 2 WASHER, M6 Shakeproof
51 94479 1 DECAL, Danger
52 B1223 2 DECAL, Heat Shield
55 25244 12 NUT, 5/16-18 Hex
57 B1224 1 DECAL, Control Panel
58 B1473 1 ASSEMBLY, Control Box
59 NSP 1 ENGINE
60 22531 2 HHCS, 5/16-18 x 1-3/4
61 22473 4 WASHER, Flat M6
62 93221 2 DECAL, Cradle
63 94480 1 DECAL, Start Instructions
64 B96068 1 SHIELD, Heat
65 56893 5 CRIMPTITE, 10-24 x 1/2
66 NSP 1 DECAL, CSA
67 74728 1 DECAL, Neutral ground
68 76247 1 DECAL, Neutral ground
69 20566 1 DECAL, 1-800
70 B4986 1 DECAL, Ground
Items Not Illustrated:
37806 120 Volt AC 30 Amp Locking
Plug
43438 120/240 Volt AC 30 Amp
Locking Plug
65787 Battery Charge Cable
72347 Spark Plug
73111 Air Filter Element
84882 Spark Plug Wrench
84883 Cord Wrap
B1479 Generator Owners Manual
PARTS LIST  MAIN UNIT
