MEGAFORCE 6500 Extended Life Generator
5
Your generator requires some assembly and is ready
for use after it has been properly serviced with the
recommended oil and fuel.
If you have any problems with the assembly of your
generator, please call the generator helpline at
1-800-270-1408.
IMPORTANT: Any attempt to run the unit before it has
been serviced with the recommended oil will result in
an engine failure.
REMOVE GENERATOR
FROM CARTON
Set the carton on a rigid flat surface with This Side
Up arrows pointing upward.
Carefully open the top flaps of the shipping carton.
Review Cold Weather Operation on page 9.
Cut down corners at one end of carton from top to
bottom and lay that side of carton down flat.
Remove all packing material, carton fillers, etc.
Remove the generator from the shipping carton.
CARTON CONTENTS
Check all contents. If any parts are missing or
damaged, call the generator helpline at
1-800-270-1408.
The generator
Wheel and lift kit
Generator and engine owners manuals
Locking 20 Amp and 30 Amp plugs
Battery charge cables
Battery tray mounting bracket/hardware
Spare spark plug and air filter element
Spark plug wrench
INSTALL WHEEL AND LIFT
KIT
You need a socket wrench with 1/2" or 13mm sockets
to assemble wheel/lift kit.
Install Wheel Kit as follows: (See Figure 2)
Place the generator on a hard flat surface.
Temporarily raise unit on blocks to ease assembly.
Lift Bar
45mm Capscrew
45mm Capscrew
Flat Washer
20mm
Capscrew
Flat Washer
Lock Nut
Lock Nut
Lock
Nut
30mm Capscrew
Vibration Mount
Support Leg
Wheel
Spacer
Retaining Pin
Axle
Wheel
Handle
Figure 2 Assemble Wheel Kit
Lock
Nut
