General Information
Owner
’s Manual for ML
T6SMD
Light T
ower
27
About Screen
See
Figure 2-19
.
The
About (
) screen contains
information about the con
t
roller such as the controller’s
date and time, the product and USB identificatio
n
number
, and the application and engine version.
Figure 2-19. About Sc
reen
08/27/2015 04 22PM
Product L401MKII A4
U ID 21CFB579D
SB
01970
30
32
Table of Contents
Default Chapter
3
Table of Contents
3
Section 1: Introduction and Safety
5
Introduction
5
Read this Manual Thoroughly
5
Safety Rules
5
How to Obtain Service
5
General Hazards
6
Explosion and Fire Hazards
6
Trailer Hazards
6
Electrical Hazards
7
Battery Hazards
7
Fuel Hazards
8
Engine Safety
8
Operating Safety
9
Positioning the Unit
9
Starting the Unit
9
Raising and Lowering the Mast
9
Service Safety
10
Towing Safety
10
Hitch and Coupling
10
Running Lights
10
Wheels and Tires
10
Safe Towing Techniques
10
Reporting Trailer Safety Defects
11
Safety and Operating Decals
12
Section 2: General Information
17
Specifications
17
Unit Serial Number Locations
18
Trailer Tongue Storage and Tow Positions
19
Place Trailer Tongue in Tow Position
19
Place Trailer Tongue in Storage Position
20
Unit Dimensions
21
Component Locations
22
Control Panel
24
Control Panel Features and Functions
25
Ecospeed Engine
25
Powerzone-DLA
26
Controller Features and Functions
26
Operator Screens
27
Section 3: Operation
33
Light Tower Setup
33
Prestart Checklist
34
Raising the Mast-Manual Winch
34
Raising the Mast-Electric Winch (if Equipped)
35
Preparing for Start-Up
36
Select Auto Mode or Manual Mode
36
Configure for Intended Use
36
Manually Starting the Unit
36
Light Operation
37
Engine Derating
37
Wet Stacking
37
Dusk to Dawn Sensor
38
Customer Convenience Receptacles
38
Shutting down the Unit
38
Automatic Shutdown
38
Lower Radiator Hose Heater (if Equipped)
38
Use and Maintenance
38
Tandem Tow (if Equipped)
39
Telemetry (if Equipped)
39
Spark Arrester (if Equipped)
39
Lowering the Mast-Manual Winch
39
Lowering the Mast-Electric Winch (if Equipped)
40
Electrically Lowering the Mast
40
Manually Lowering the Mast
40
Towing the Unit
40
Lifting the Unit
41
Tying down the Unit
41
Section 4: Maintenance
43
Emissions Information
43
Daily Walk-Around Inspection
43
General Maintenance
43
Preparing for Service
43
Cleaning the Unit
43
Inspecting the Unit
43
Basic Maintenance Schedule
44
Resetting the Maintenance Alarms
45
Winch Use, Operation, and Maintenance-Manual
45
Prior to Use
45
Operation
45
Maintenance
45
Winch Use, Operation, and Maintenance-Electric
45
Winch Mechanical Brake
46
Trailer Wheel Bearings
46
Jack Maintenance
46
Section 5: Troubleshooting
47
General Troubleshooting
47
Section 6: Wiring Diagrams
49
AC Wiring
49
DC Wiring-Control Box
50
DC Wiring
51
DC Wiring-Electric Winch Option
52
Trailer Wiring
53
Section 7: Service Log
55
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Generac Power Systems MLT6SMD and is the answer not in the manual?
Ask a question
