Electrical Connections
Installation Manual for Generac PWRCell Inverter 19
NOTE: See Figure 5-6. On systems that do not include battery storage but battery storage is expected in the future,
install a protected loads panel during inverter installation. The protected loads panel will be fed by the grid while the
system operates in Grid Tie mode.
Figure 5-6. Configuration for Adding Batteries Later
A
B
C
D
E
009998
G
A PV Array
B PWRcell Inverter
C Protected Loads Panel
D Protected Loads Disconnect
E AC Main Panel
G Utility
