Installation Manual for Generac PWRcell Inverter 5
General Information
Section 2: General Information
Specifications
Description Units XVT076A03 XVT114G03
Max. cont. grid-tied AC power @ 122°F (50ºC) kW 7.6 11.4
Max. cont. islanded AC power @ 104°F (40°C)
with single 6 module battery cabinet
1
kW 9.0 9.0
Max. cont. islanded AC power @ 104°F (40°C)
with 2 battery cabinets (8 modules minimum)
kW 11.0 Range 9.6 to 11.0*
Max. cont. Islanded AC power @ 122°F (50°C) kW 8.8 Range 7.5 to 8.8*
Peak motor starting current (2 sec) A rms 50
Normal output frequency AC Hz 60
Grid Voltage Line to Neutral (L-N) VAC 120
Grid Voltage Line to Line (L-L) VAC 240 208
Peak efficiency % 97.3 97.7
CEC weighted efficiency % 96.5 97.5
AC terminals wire size AWG 14 to 6
DC terminals wire size AWG 18 to 6
STOP terminals wire size AWG 28 to 16
Weight lb (kg) 62.7 (28.4)
Thermal management - forced convection
Weatherization rating - NEMA Type 3R
Enclosure Material - powder-coated steel
Description Units Min Nominal Max
REbus voltage V dc 360 380 420
REbus current
V dc
30
2
REbus Input short circuit current
3
V dc 30
REbus Input source backfeed current to input source V dc 30
Output power factor rating AC - 1
Operating voltage range AC, XVT076A03 (L-N) V rms 108 120 130
Operating voltage range AC, XVT076A03 (L-L)
V rms 216 240 260
Operating voltage range AC, XVT114G03 (L-N) V rms 108 120 130
Operating output voltage range AC, XVT114G03 (L-L) V rms 184 208 228
Continuous output current AC grid-tied A rms 32
PCS controlled current grid-tied A rms 32
Continuous output current AC islanded A rms 42
Output fault current duration A / ms 50 / 2,000
Full Power operating ambient temperature range
4
°F (°C) -4 (-20) +122 (+50)
Utility interconnection voltage and frequency trip limits and trip
times
See
Voltage and Frequency Trip Thresholds for more
information.
Trip voltage and frequency limits
Trip voltage accuracy
Trip time accuracy
% 2% +/- 2 cycles
1
Peak performance
2
Inverter limits its REbus current to adhere to its AC power rating. Total REbus current capability from multiple REbus
sources may safely exceed this value as the inverter safely limits the amount utilized.
3
Rating for one DC input. Four total.
4
Includes ambient temperature rising from inverter operation.
* In Island mode XVT114G03 Protected loads only supply 2 phases 120 VAC L-N, 208 L-L which results in lower power than in
grid tied 3 phase mode. The low value of the range is for full L-L loading while high value of the range is full L-N loading.
