3.9 Setup Mode Selection Table
This section helps the operator make selections during the Setup mode. It is
recommended that the operator fill-in the selections in the proper blanks and then use
this page as a reference while programming the Model 2180A. The table shown below
indicates the order of options in the Setup mode. To the right of the option entry is a
description of the choices that are available for that option.
OPTION DESCRIPTION
ENTER
SELECTION
Password
Enter the Password, if the Password is enabled
High Alarm
Options
Set the Energized (En) / De-Energized (dE) Option
Set the Latching (LA) / Non-Latching (nL) Option
Set the High alarm set point
Low Alarm
Options
Set the Energized (En) / De-Energized (dE) Option
Set the Latching (LA) / Non-Latching (nL) Option
Set the Low alarm set point
Password
Options
Set the Password to be Disabled (Pd) or Enabled
(PE)
If the Password option to be changed from
Disabled to Enabled:
Set the password digits
Left__________
Right__________
Table 8: Setup Display Options
