Model 2180A
36
7.6 Product Configuration Table
MODEL 2180A
SINGLE CHANNEL H2S CONTROLLER
A B C D E
1 1 01 1 1
A. CONTROLLER
2180A Model 2180A Controller 3.0 lbs.
1 (Std) -P1 110 VAC/24VDC
2 - P2 220 VAC/24 VDC
B. RELAY – STATE - NC
1 (STD) RS 1NC LATCH ALARM, NON-LATCH WARN, DE-ENERGIZED
2 RS 2NC LATCH ALARM, NON-LATCH WARN, ENERGIZED
3 RS 3NC LATCH ALARM, LATCH WARN, DE-ENERGIZED
4 RS 4NC LATCH ALARM, LATCH WARN, ENERGIZED
5 RS 5NC NON-LATCH ALARM, NON-LATCH WARN, DE-
ENERGIZED
6 RS 6NC NON-LATCH ALARM, NON-LATCH WARN, ENERGIZED
7 RS 7NC NON-LATCH ALARM, LATCH WARN, DE-ENERGIZED
8 RS 8NC NON-LATCH ALARM, LATCH WARN, ENERGIZED
C. H2S – SENSOR
00
NONE
No Sensor 0.5 Lbs.
01 (STD) 50445-1 Sensor Al 0 to 100 PPM H2S 0.5 Lbs.
02 50445-5 Sensor Al 0 to 50 PPM H2S 0.5 Lbs.
03 50445-9 Sensor Al 0 to 20 PPM H2S 0.5 Lbs.
04 50448-1 Sensor SS 0 to 100 PPM H2S 0.5 Lbs.
05 50448-5 Sensor SS 0 to 50 PPM H2S 0.5 Lbs.
06 50448-9 Sensor SS 0 to 20 PPM H2S 0.5 Lbs.
07 50454-1 Sensor PTB AL 0 to 100 PPM H2S 0.5Lbs.
08 50454-5 Sensor PTB AL 0 to 50 PPM H2S 0.5 Lbs.
09 50454-9 Sensor PTB AL 0 to 20 PPM H2S 0.5 Lbs.
11 51457-1 Sensor SS Atex H2S 0-100 (Replaces 50457-1) 0.5 Lbs.
12 51457-1L Sensor SS Atex H2S 0-100 (W/Lugs) 0.5 Lbs.
13 51457-5 Sensor SS Atex H2S 0-50 (Replaces 50457-5) 0.5 Lbs
14 51457-5L Sensor SS Atex H2S 0-50 (W/Lugs) 0.5 Lbs.
15 51457-9 Sensor SS Atex H2S 0-20 (Replaces 50457-9) 0.5 Lbs.
16. 51457-9L Sensor SS Atex H2S 0-20 (W/Lugs) 0.5 Lbs.
D. H2S METER SCALE
1 (STD) H2S1 99 PPM SCALE
2 H2S2 50 PPM SCALE
3 H2S3 20 PPM SCALE
