Page 12
KCD-17, 19, 21 & 23” Series
ASSEMBLY & OPERATION INSTRUCTIONS
PREPARE THE MACHINE FOR OPERATION (SETTING UP)
The KCD machine is packed in two separate boxes. The machine is in box 1 of 2, and the handle is in
carton 2 of 2. Unpack the machine and handle carefully. Insert the handle into the handle adaptor
socket and tighten the two square head screws to hold the handle firmly in place. DO NOT OVER
TIGHTEN SCREWS. Damage could incur to the handle adaptor threads and will cause the handle to be
loose and unsafe. Connect the male motor lead from motor to the female handle lead from handle.
BRUSH, PAD DRIVER & PAD INSTALLATION:
WARNING: Make sure the power cord is disconnected from the electrical outlet before installing or re-
moving the brush, pad driver or pads from machine.
1.) Unwrap the power cord from handle. Do not plug cord into wall outlet. Lock the handle in the up-
right position. Flip the wheels down and tilt the machine back on the wheels and handle so that the
machine is resting on handle and the bottom of machine is up in the air.
2.) Align the lugs of the gear box with the corresponding slots in the brush or pad driver and turn the
brush or pad driver counterclockwise to lock it in place. Install pad in center of pad driver and
lower machine to floor.
3.) To remove brush or pad driver flip the wheels down and tilt machine back so that it rests on the
wheels and handle. Turn the brush or pad driver clockwise until it disengages and lift off. Do not
store the machine with the brush or pad driver installed.
HOW TO OPERATE MACHINE
1.) Unwrap the power cord. Do not plug in yet.
2.) Install the brush, pad driver with pad or attachment.
3.) Lower the handle to the desired operating position and retighten.
4.) Lift wheels off floor.
5.) Plug in cord into a properly grounded outlet.
6.) Place both hands on the handle grips with your fingers around the on/off levers which extends from
one side to the other side underneath the hand grips.
WARNING!
Be prepared to control the machine as soon as the motor starts.
7.) Carefully push the Safety Lock Tabs located on either side of the switchbox and compress the on/off
levers to start machine. Note: When the switch levers are released, the machine shuts off immedi-
ately.
