05
5-93
Face-Level (B, D, F)
Air flow is directed toward the upper
body and face. Additionally, each outlet
can be controlled to direct the air
discharged from the outlet.
Bi-Level (B, D, C, E, F)
Air flow is directed towards the face and
the floor.
Floor-Level (A, C, D, E, F)
Most of the air flow is directed to the
floor, with a small amount of the air
being directed to the windshield and side
window defrosters.
)ORRU'HIURVW/HYHO
(A, C, D, E, F)
Most of the air flow is directed to the
floor and the windshield with a small
amount directed to the side window
defrosters.
OIK050085
Defrost-Level (A)
Most of the air flow is directed to the
windshield with a small amount of air
directed to the side window defrosters.
Front
OIK050049
Rear
OIK050086
Instrument panel vents
The outlet vents can be opened
(
) or closed ( ) separately using the
thumbwheel.
Also, you can adjust the direction of air
delivery from these vents using the vent
control lever as shown.
