09
9-51
Fuse Name
Fuse Rating Circuit Protected
WASHER
15A Multifunction Switch
MDPS
10A MDPS Unit
DRIVER
P/SEAT
30A Driver IMS Control Module, Driver Seat Manual Switch
PASSENGER
P/SEAT
30A
Passenger Seat Manual Switch, Passenger Walk In Relay
Module
DRIVER
P/WINDOW
25A
Driver Safety Power Window Module, Rear Safety Power
Window Module LH, Rear Power Window Switch LH
MODULE6
10A
Around View Monitor, IBU, Emergency Call Module,
AMP, Electronic ATM Shift Lever, Overhead Console
Lamp, A/V & Navigation Head Unit, Low DC-DC
Converter (Audio/AMP)
A/CON
10A
A/C Control Module, A/C Switch, PM Sensor (A/C), E/R
Junction Block (RLY.6), Diesel Junction Block (RLY.3/4)
MODULE4
10A
Head Lamp LH/RH, Auto Head Lamp Leveling Device
Module
To Next Page
