Engine compartment fuse panel
Fuse Name
Fuse Rating Circuit Protected
ALT
175A
225A
Alternator, Fuse - F2,
Multi Fuse 1 - F4, F6, F7, F8, F9, F10, F11, F12, F13
C/FAN3
125A
[G6DP - BLDC Motor] Cooling Fan Controller
GLOW
[D4HB] Glow Relay Unit
START
30A RLY. 7 (Start Relay)
C/FAN1
80A [BLDC Motor] Cooling Fan Controller
B+3
50A
ICU Junction Block (Fuse - F5, Leak Current Autocut
Device Fuse - F2, F4, F13, F14, F21, F22)
B+2
50A ICU Junction Block (Fuse - F27, F35, F43, F51, F52)
B+1
50A ICU Junction Block (Fuse - F28, F29, F37, F45, F53)
EOP
50A [With ISG] Electric Oil Pump Module
ESP1
40A ESP Control Module
ESP2
40A ESP Control Module
BLOWER
40A RLY. 6 (Blower Relay)
IG2
30A PCB Block (IG2 Relay)
MDPS
100A MDPS Unit
B+4
60A
PCB Block
(Engine Control Relay, Fuse - F4, F5, F13, F22)
C/FAN2
60A [DC Motor] RLY. 9 (Cooling Fan Relay)
E-CVVT1
40A [G4KL] RLY. 8 (E-CVVT Relay)
TRAILER
40A Trailer Connector
FUEL HEATER
40A Diesel Junction Block (RLY.1 (Fuel Filter Heater Relay))
PTC HEATER1
30A Diesel Junction Block (RLY.2 (PTC Heater #1 Relay))
PTC HEATER2
30A Diesel Junction Block (RLY.3 (PTC Heater #2 Relay))
PTC HEATER3
30A Diesel Junction Block (RLY.4 (PTC Heater #3 Relay))
To Next Page
