2. Press the ↵ (Edit) key to save the new value and return to the System
Settings menu. Verify that the number is displayed in the status line at the
bottom of the display when Screen Contrast is highlighted.
Software Version
The Software version menu displays the version number of the software
installed and is for information only. The menu also displays the current time
and date.
I/O Board Software
This menu displays the version number of the I/O board software installed and
is for information only.
Temperature Units
This menu allows the engineer to change the
way that the temperature is displayed, either
°C or °F, on the LCD when the machine is in
standby mode. Use the
▲ (up) or ▼ (down)
keys to set the required option followed by the
↵ (Edit) key to store/save it (indicated by the
filled radio button).
Idle Screen Options
This menu allows the engineer to configure the LCD so that it displays either
the time or the time and water temperature with the standby message when
idle. To configure the idle screen options, proceed as follows:
1. From the System Settings menu press the
▼ (down) key to highlight Idle
Screen Options and press the ↵ (Edit) key to access the menu.
2. Press the
▼ (down) key to highlight the
required option, eg Time and Temp
(indicated by the filled radio button). The
LCD will display the screen as shown
opposite. Press the ↵ (Edit) key to return
to the System Settings screen. With Idle
Screen Options highlighted, verify that the status line confirms the option
is set to Time and Temp.
3. Press the X (Exit) key until the machine
exits the engineers program into standby
mode. The LCD will display the standby
message with the time and date as shown.
Please Make
a Selecti on
Time: 10:45 Temp: 90C
Temperature Units
Celsius ( ¡C)
Fahrenheit ( ¡F)
Idle Screen Option s
Time
Time and Tem p
None
Technical Manual
61
