23
Operators Manual
Carefully remove the waste tray from the
machine.
Remove the waste tray grille and empty the
contents of the tray. Wash the tray and grille
thoroughly and where necessary, sanitise using
the diluted bactericidal cleaner solution.
Dry both components using a clean, dry cloth.
Reassemble the waste tray and grille and refit to
the machine.
4.5.8 Cup Check
Check the levels of the cups in the cup stack.
Where necessary, refill with correct sized cups.
DO NOT TOUCH THE CUPS WITH YOUR
HANDS. Allow the cups to drop into the cup
stack directly from the packaging.
Important: Do not fill the tube directly above
the cup dispense position. Allow the cup turret
motor to rotate a full tube to the cup dispense
position. Rotating the cup turret by hand will
damage the mechanism.
Note: If paper cups are being loaded, each pack of cups must first be
inspected for damage to the cup rims. Damaged cups must not be used.
Rotate the cup turret assembly back to its operating position. Ensure that
the unit ‘locks’ into place.
4.5.9 Cash Box
Un-lock the cashbox (if fitted) located on the
rear of the door and remove from the machine.
Remove any coinage from the cashbox. Refit the
cashbox to the machine, turning the lock to
secure.
Open the coin mechanism cover and wipe the
inside with a damp cloth.
Check the coin tubes and refill if required.
