Page #16 background imageLoading...
Page #16 background image
16
5 REMOVING AND INSTALLING THE COVER
The cover must be removed to set up the drive. See Section 5.1, below, for
instructions on removing the cover. See Section 5.2, on page 17, for instructions on
installing the cover.
Model KBWA-23D is housed in a NEMA 1 / IP20 vented enclosure. Models
KBWA-22D, 21D, 2P6D, 2P3D are housed in a NEMA 1 / IP50 non vented enclosure.
Note: To install the supplied Forward-Stop-Reverse Switch, remove the cover, as
described in Section 5.1, below, and follow the instructions in Section 6, on page 18.
Jumper Settings: See Section 7, on pages 19 – 22.
AC Line, Motor, and Ground Connections: See Sections 10, on pages 24 – 26.
Trimpot Adjustments: See Section 12, on pages 28 – 31.
WARNING! Disconnect the main power before removing or installing the
cover.
WARNING! After disconnecting the main power to the drive, wait at least
30 seconds before removing the cover.
WARNING! To prevent accidental contact with high voltage, it is required
that the cover be properly installed onto the drive after all wiring and setup is
complete. It offers protection against electric shock which limits the potential
liability to the equipment manufacturer and installer.
5.1 REMOVING THE COVER
Remove the two screws on the cover and slide it off the drive's base. Be careful not to
separate the wires from the drive to the cover's On/Off AC Line Switch and Main
Speed Potentiometer.
To facilitate wiring the drive, place the cover on top of the case, as shown in Figure 5,
on page 17.
