14.1 ILLUMINATED ON/OFF AC LINE SWITCH
The On/Off AC Line Switch will illuminate when the AC line is applied to the drive and
the switch is in the ON ("I") position.
14.2 POWER ON LED (PWR)
The "PWR" LED, located on the drive's PC board, will illuminate green when the AC
line is applied to the drive and the On/Off AC Line Switch is set to the on ("I") position.
14.3 STATUS LED (ST)
The "ST" LED, located on the drive's PC board, is a tricolor LED which provides
indication of a fault or abnormal condition. The information provided can be used to
diagnose an installation problem such as incorrect input voltage, overload condition,
and drive output miswiring. It also provides a signal which informs the user that all
drive and microcontroller operating parameters are normal. Table 7, summarizes the
"ST" LED functions.
TABLE 7
OPERATING CONDITION AND STATUS LED INDICATOR
Status LED
Operating Condition
Flash Rate
1
Color
Normal Operation Slow Green
Overload (120% - 160% Full Load) Steady Red
2
Overload Trip (Drive Timed Out) Quick Red
2
Short Circuit Slow Red
Undervoltage Quick Red/Yellow
Undervoltage Recovery
3
Quick Red/Yellow/Green
Overvoltage Slow Red/Yellow
Overvoltage Recovery
3
Slow Red/Yellow/Green
Stop Steady Yellow
Notes: 1. Slow Flash = 1 second on and 1 second off. Quick Flash = 0.25 second
on and 0.25 second off. 2. In Manual Start Mode, when the Overload is removed,
before the I
2
t times out and trips the drive, the Status LED will flash green. 3. In
Manual Start Mode, when the Undervoltage or Overvoltage condition is corrected,
the Status LED will flash Red/Yellow/Green.
