ADMA 3.0
USER MANUAL
Document Revision 2.01 | 2021 Page 3/137
TABLE OF CONTENTS
INTRODUCTION 6
ADMA PRODUCT FAMILY 7
2.1 ADMA-G 8
2.2 ADMA-SPEED 8
2.3 ADMA-SLIM 8
2.4 ORDERING OPTIONS 8
SCOPE OF DELIVERY 9
3.1 ADMA-G COMPONENTS 9
3.2 ADMA-SPEED COMPONENTS 10
3.3 ADMA-SLIM COMPONENTS 11
FRONT VIEW AND INTERFACES 12
4.1 ADMA-G 12
4.2 ADMA-SPEED 14
4.3 ADMA-SLIM 16
ADMA WEBINTERFACE 18
5.1 TPC/IP SETTINGS 19
5.2 CONNECT TO THE ADMA WEBINTERFACE 21
5.3 ADMA-SYSTEM AND GNSS-RECEIVER INFORMATION 21
ADMA LABORATORY BENCH TEST 22
7.1 SETUP AND CABLING 22
7.2 ADMA CONFIGURATION FOR BENCH TESTING 23
7.3 SETUP THE DATA ACQUISITION (DAQ) 29
7.4 STATIC TEST 30
7.5 DYNAMIC TEST 33
INSTALLATION AND CABLING INSIDE THE VEHICLE 35
8.1 POINT OF INSTALLATION 35
8.2 CABLING 41
8.3 MODIFY THRESHOLD FOR AUTOINIT, HEADING CTRL. AND DUAL ANTENNA USE 43
8.4 STANDSTILL DETECTION 44
8.5 MODIFY THRESHOLDS FOR QUALITY INDICATION 47
8.6 RELATIVE COORDINATE SYSTEM 49
8.7 COMPENSATING AN ADMA MISALIGNMENT 51
8.8 COMPENSATING THE INSTALLATION POSITION 52
