Genie GPS-IC Series User Manual

NOTE: Accessories vary by model.
FASTENERS -
Shown full size. See Parts List for description.
105
10 4
103
101
106
12 6
12 4
12 5
Lag Screw, 1/4” x 2”
Cotter Pin
Clevis Pin
Bolt, 3/8”-16 x 7/8”
Phillips Hex Head Screw, No. 10 x 1-1/4”
Insulated Staple
Bolt, 5/16”-18 x 1/2”
100
69
112
79
81
82
127
N/A
N/A
96
91
92
90
89
Pan Head Screw #6 x 1-1/4”
128
N/A
10
PARTS IDENTIFICATION FOR HELP-1.800.354.3643 OR GENIECOMPANY.COM
9
N/A
Hex Head Screw
No. 8 x 3/4”
Cold Head Pin
Pan Head
Phillips Screw
No. 8 x 5/8”
Speed Nut
OR
N/A
N/A
Nut, 3/8-16
1/4”-20 x 3/4”
Self-Drilling Screw
Bolt, #10-24 x 1/2”
5
Wall Control Screw
N/A
remotes
vary by model
N/A
