Genie GS-3232 Service And Repair Manual

April 2017
Table of Contents
xii GS-30 • GS-32 • GS-46 • GS-47 Part No. 1272217
Section 4 Diagnostics ....................................................................................................... 155
Introduction ........................................................................................................ 155
GCON I/O Map without Load Sense (all machines except GS-3232) ............... 158
GCON I/O Map with Load Sense (all machines except GS-3232) .................... 159
GCON I/O Map without Load Sense GS-3232 only) ......................................... 160
GCON I/O Map with Load Sense (GS-3232 only) ............................................. 162
Operation Indicator Codes (OIC) ....................................................................... 164
Diagnostic Trouble Codes (DTC) ....................................................................... 164
Troubleshooting "HXXX" and "PXXX" Faults ..................................................... 165
Fault Inspection Procedure ................................................................................ 166
Type "HXXX" Faults ........................................................................................... 168
Type "PXXX" Faults ........................................................................................... 172
Type "UXXX" Faults ........................................................................................... 173
Type "FXXX" Faults ........................................................................................... 176
Type "CXXX" Faults ........................................................................................... 179
Battery Charger .................................................................................................. 181
Charger Fault Codes .................................................................................... 182
Charger Error Codes .................................................................................... 183

Genie GS-3232 Specifications

General

Lift Capacity	500 lbs
Power Source	Electric
Battery Voltage	24 V
Gradeability	25%
Platform Height	32 ft
Machine Width	32 in
Drive Speed - Stowed	3.5 km/h
Drive Speed - Raised	0.5 mph
Drive Speed	3.5 km/h
Overall Width	32 in
Working Height	38 ft
