Genie GS-3232 User Manual

Operator's Manual Sixth Edition • Ninth Printing
Work Area Safety
14 GS-30 • GS-32 • GS-46 • GS-47 Part No. T107026
If equipped with outriggers
Do not set the machine up where it cannot be
leveled using only the outriggers.
Do not adjust the outriggers while the platform is
raised.
Do not drive while the outriggers are lowered.
Crushing Hazard
Keep hands and limbs out of scissors.
Keep hands clear when folding rails.
Do not work under the platform or in the scissor
links without the safety arm in place.
Use common sense and planning when operating
the machine with the controller from the ground.
Maintain safe distances between the operator, the
machine and fixed objects.
Operation on Slopes Hazards
Do not drive the machine on a slope that exceeds
the slope and side slope rating of the machine.
Slope rating applies to machines in the stowed
position.
Model
Maximum slope
rating, stowed
position
Maximum side slope
rating, stowed
position
GS-1530
30% (17°) 30% (17°)
GS-1930
25% (14°) 25% (14°)
GS-2032
30% (17°) 30% (17°)
GS-2632
25% (14°) 25% (14°)
GS-3232
25% (14°) 25% (14°)
GS-2046
30% (17°) 30% (17°)
GS-2646
30% (17°) 30% (17°)
GS-3246
25% (14°) 25% (14°)
GS-4047
25% (14°) 25% (14°)
Note: Slope rating is subject to ground conditions
and adequate traction.

Genie GS-3232 Specifications

General

Lift Capacity	500 lbs
Power Source	Electric
Battery Voltage	24 V
Gradeability	25%
Platform Height	32 ft
Machine Width	32 in
Drive Speed - Stowed	3.5 km/h
Drive Speed - Raised	0.5 mph
Drive Speed	3.5 km/h
Overall Width	32 in
Working Height	38 ft
