Genie GS-3232 User Manual

Operator's Manual Sixth Edition • Ninth Printing
GS-30 • GS-32 • GS-46 • GS-47 Part No. T107026
Front Matter
Important
Read, understand and obey these safety rules and
operating instructions before operating this
machine. Only trained and authorized personnel
shall be permitted to operate this machine. This
manual should be considered a permanent part of
your machine and should remain with the machine
at all times. If you have any questions, contact us.
Contact Us:
Internet: www.genielift.com
E-mail: awp.techpub@terex.com
Contents
Introduction ........................................................... 1
Symbol and Hazard Pictorials Definitions ............. 3
General Safety ...................................................... 5
Personal Safety ................................................... 10
Work Area Safety ................................................ 11
Legend ................................................................ 20
Controls ............................................................... 23
Inspections .......................................................... 28
Operating Instructions ......................................... 54
Transport and Lifting Instructions ....................... 67
Maintenance ....................................................... 72
Specifications ...................................................... 74
Copyright © 1997 Terex Corporation
Sixth Edition: Ninth Printing, December 2014
Genie is a registered trademark of Terex South Dakota, Inc. in
the U.S.A. and many other countries. “GS” is a trademark of
Terex South Dakota, Inc.
These machines comply with
ANSI/SIA A92.6
CAN B.354.2

Genie GS-3232 Specifications

General

Lift Capacity	500 lbs
Power Source	Electric
Battery Voltage	24 V
Gradeability	25%
Platform Height	32 ft
Machine Width	32 in
Drive Speed - Stowed	3.5 km/h
Drive Speed - Raised	0.5 mph
Drive Speed	3.5 km/h
Overall Width	32 in
Working Height	38 ft
