Operator's Manual Sixth Edition • Ninth Printing
Symbol and Hazard Pictorials Definitions
4 GS-30 • GS-32 • GS-46 • GS-47 Part No. T107026
Batteries used as
counterweights
Chock the wheels Release brakes
Grounded AC
3-wire only
Replace damaged
wires and cords
Wheel load Transport diagram Tiedown
Lanyard anchorage
points
No smoking
Voltage rating for
power to platform
Pressure rating for
air line to platform
Side force Wind speed
Maximum capacity

Genie GS-3232 Specifications

General

Lift Capacity	500 lbs
Power Source	Electric
Battery Voltage	24 V
Gradeability	25%
Platform Height	32 ft
Machine Width	32 in
Drive Speed - Stowed	3.5 km/h
Drive Speed - Raised	0.5 mph
Drive Speed	3.5 km/h
Overall Width	32 in
Working Height	38 ft
