Genmitsu 3018-PRO - Step 8 Z - Axis Assembly

19
Step 8 Z - Axis Assembly
Step 1: Prepare the Z Axis Carriage and Leadscrew.
Compress the Anti-Backlash Spring into the Hole shown below.
Use the Copper Nut to slide into the spring and hold it into place.
While compressed, thread the Leadscrew through the assembly.
14
34
37
