Genmitsu 3018-PRO - Part 1 - Unboxing

04
(2) Aluminum Profile
20 x 40 x 290 mm
(2) Aluminum Profile
20 x 20 x 360mm
1
(2) Guide Rail
Y Axis, Ø10 x 290mm
5
10 11
2
Lead Screw 365mm
6 7 8
9
3 4
Aluminum Profile
300 x 180mm
(2) Guide Rail
X Axis, Ø10 x 360mm
Lead Screw 295mm Bakelite Resin Plate A
Bakelite Resin Plate B Bakelite Resin Plate C Bakelite Resin Plate D (2) Stepper motor
12
Please make sure all the following parts are included. If you are missing any part or have any questions, please email us at
support@sainsmart.com.
Part 1 - Unboxing
