32EZiSYSTEM, How to Use the Locator
The signal (current) applied by the transmitter decreases at a uniform rate as it travels along the
service. This can help to identify the service layout, as connections off it have a corresponding
reduction in current. A sudden reduction in current may indicate damage to the service.
20
360
340
330
110
