Zenith15/25 Pro | 24Technical Data
6.1.5 Technical Data
Dimensions
Weight
*without battery
Recording GNSS raw data can be recorded on a microSD card.
1 GB capacity is typically sufficient for about 7000 h dual frequency logging at a 15 s rate (average
constellation).
Power
Operating times

Operating times may vary depending on the temperature and battery age.
6.1.6 Environmental specifications
Environmental specifi-
cations
6.2 Conformity to National Regulations
Conformity to national
regulations
Height: 95 mm (3.7")
Diameter: 198 mm (7.8")
Zenith15/25 Pro GSM: 1.075 kg*
Zenith15/25 Pro GSM-UHF: 1.100 kg*
Internal battery: Li-Ion battery 7.4 V/2.6 Ah
External power input: 10.5 V to 28 V DC with ZDC225 cable
Power consumption: Typically 2.0 W without radio
Equipment type Zenith15: Operating
time ZBA201
Zenith25 Pro: Operating
time ZBA201
Static 7.5 h 9 h
Rover (radio; Microhard nL400, receive) 5 h 6 h
Rover (Digital cellular phone; Cinterion PHS8) 5 h 6 h
Temperatures (°C):
Instrument: -40 to +65 (operation) -40 to +80 (storage)
Battery: -20 to +55 (operation) -40 to +70 (storage)
Protection:
IP68 (IEC 60529)
Vibration:
Vibration test according to ISO 9022-36-05
Shock:
Withstands a 2 m (6.6 ft) pole topple over onto hard surface.
Humidity:
100% condensing
The effects of condensation are to be effectively counteracted by periodically drying out the instrument.
• FCC Part 15 (applicable in US)
• Hereby, GeoMax AG, declares that the product Zenith15/25 Pro is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC and other applicable European
Directives. The declaration of conformity is available from GeoMax AG.
• This Class 2 equipment may be operated in: AT, BE, CY, CZ, DK, EE, FI, FR, DE, GR, HU, IE, IT, LV,
LT, LU, MT, NL, PL, PT, SK, SI, ES, SE, GB, IS, LI, NO, CH, BG, RO and TR.
Class 2 equipment according European Directive 1999/5/EC (R&TTE) for
which following EEA Member States apply restrictions on the placing on the
market or on the putting into service or require authorisation for use:
• France
• Italy
• Norway (if used in the geographical area within a radius of 20km from
the centre of Ny-Ålesund)
• The conformity for countries with other national regulations not covered by the FCC part 15 or Euro-
pean directive 1999/5/EC has to be approved prior to use and operation.
